Printer parts diagram for: C4125-67901
C4125-67901 is represented by #13 in the diagram below.
1
RB1-8947-000CN Panel
Separation roller access panel
11
RB1-8961-000CN Lifter
Arm lifter - White plastic arm that holds top left side metal corner piece up when loading paper in tray
12
RB1-8962-000CN Lifter
Arm lifter - White plastic arm that holds top right side metal corner piece up when loading paper in tray
13
C4125-67901 Tray
500 sheet universal paper tray assembly - This is ONLY the tray that holds the paper, NOT the optional feeder assembly (C4124A) that the printer sits on - Holds A5 to Legal size paper - Replaces C3122A Tray
2
RF5-2489-000CN Spindle
Separation roller mounting assembly
3
RB1-8948-000CN Gear
Separation roller drive gear
4
RB1-8946-000CN Bushing
Separation roller bushing
5
RB1-8945-000CN Coupler
Separation roller/gear coupler
6
RS5-2622-020CN Spring
Separation roller tension spring
7
RF5-2760-000CN Stop
Paper stop - Used for the 500-sheet paper tray
