Printer parts diagram for: RG5-6041-070CN


RG5-6041-070CN is represented by #4 in the diagram below. 1 RG5-6038-040CN Sensor Waste toner sensor assembly - Mounts to the front of the print engine frame assembly 2 RG5-6040-050CN Bottle Waste toner collection bottle assembly 3 RG5-6121-030CN Lever Toner cartridge release lever assembly - Four used 4 RG5-6041-070CN Cleaner Intermediate Transfer Belt (ITB) cleaner assembly - Moves excess toner from ITB to catch tray assembly - Small blue handle to left of large green one 5 RB2-7207-000CN Tray Waste toner catch tray - Slides beneath Intermediate Transfer Belt (ITB) cleaner assembly to collect waste toner

RG5-6041-070CN is represented by #4 in the diagram below.

RG5-6038-040CN Sensor Waste toner sensor assembly - Mounts to the front of the print engine frame assembly

RG5-6040-050CN Bottle Waste toner collection bottle assembly

RG5-6121-030CN Lever Toner cartridge release lever assembly - Four used

RG5-6041-070CN Cleaner Intermediate Transfer Belt (ITB) cleaner assembly - Moves excess toner from ITB to catch tray assembly - Small blue handle to left of large green one

RB2-7207-000CN Tray Waste toner catch tray - Slides beneath Intermediate Transfer Belt (ITB) cleaner assembly to collect waste toner
