Printer parts diagram for: RK2-2728-000CN
RK2-2728-000CN is represented by #4 in the diagram below.
3
RC2-6689-000CN Holder
Interlock switch holder - Holds 24V interlock switch (SW2)
4
RK2-2728-000CN Fan
Delivery Fan (FM3) - Provides air to the paper delivery area
5
RC2-8357-000CN Holder
Duplexing fan holder - Holds fusing fan (FM2)
6
RC2-7092-000CN Spring
Leaf grounding spring
7
RC2-6670-000CN Cover
Handle guide cover
