HP Printer Parts Diagram Finder

Printer parts diagram for: Q6651-60260


Q6651-60260 is represented by #4 in the diagram below. 1 Q1271-60454 Foot Foot assembly (includes casters) - Mounts to the bottom of the printer stand legs (two used) 2 Q1271-60183 Leg Leg assy service 3 Q1271-60456 Cross Brace Cross-brace - Brace that connects and supports the two stand legs 4 Q1271-60457 Media Bin Media bin - Wire rack that mounts to the plotter stand legs and cross brace 4 Q1271-60458 Kit Hardware kit for printer stand - Includes screwdriver and screws - Used to assemble printer stand 4 Q1271-60673 Kit HDWARE KIT and SCREWS SV 4 Q6651-60260 Media Bin Bin assembly - Includes the bin support - For 42-inch plotters 5 Q1271-60459 Cover Leg cover - Covers both the left and right leg assemblies

Q6651-60260 is represented by #4 in the diagram below.

Q1271-60454 Foot Foot assembly (includes casters) - Mounts to the bottom of the printer stand legs (two used)

Q1271-60183 Leg Leg assy service

Q1271-60456 Cross Brace Cross-brace - Brace that connects and supports the two stand legs

Q1271-60457 Media Bin Media bin - Wire rack that mounts to the plotter stand legs and cross brace

Q1271-60458 Kit Hardware kit for printer stand - Includes screwdriver and screws - Used to assemble printer stand

Q1271-60673 Kit HDWARE KIT and SCREWS SV

Q6651-60260 Media Bin Bin assembly - Includes the bin support - For 42-inch plotters

Q1271-60459 Cover Leg cover - Covers both the left and right leg assemblies
