RG5-5651-030CN Printer Parts Diagram


RG5-5651-030CN is represented by #11 in the diagram below. 1 RB2-5517-020CN Mount Front fusing assembly mount 10 RG5-8034-000CN Cable Fusing assembly high voltage cable and connectors 11 RG5-5651-030CN Guide Transfer guide assembly (Ribbed plastic piece) - Has slot for the transfer roller assembly 14 C8519-69033 Fuser Assembly Fuser Assembly - Bonds toner to paper with heat - For 100V to 127V Operation 14 C8519-69036 Fuser Assembly Fusing Assembly - Bonds toner to paper with heat - For 220V to 240V OperationFusing Assembly - For 220 VAC to 240 VAC - Bonds toner to paper with heat 15 RG5-5717-020CN Contact Toner cartridge contact assembly 16 RS6-2299-000CN Spring Shutter arm spring - Provides tension for shutter arm 17 RB2-5639-000CN Arm Shutter arm for HP LaserJet M9040 MFP 18 RB2-5640-000CN Shutter Laser shutter - Cartridge shutter actuator - Piece that opens cartridge shutter as it is inserted into the printer 19 RS6-2296-000CN Spring Laser shutter spring - Provides tension for laser shutter 2 RB2-5515-000CN Rail Front Fusing Rail 3 RB2-5516-000CN Rail Rear Fusing Rail 4 RB2-5518-020CN Mount Rear fusing assembly mount 5 RB2-5523-000CN Contact Fuser electrical contact leaf spring 7 RG5-5724-050CN Holder Fuser connector holder assembly 8 RG5-8025-000CN Cable Cable assembly - Fuser power cable 9 RS5-0708-000CN Gear 21 tooth gear for HP LaserJet M9040 MFP

1

RB2-5517-020CN Mount Front fusing assembly mount

10

RG5-8034-000CN Cable Fusing assembly high voltage cable and connectors

11

RG5-5651-030CN Guide Transfer guide assembly (Ribbed plastic piece) - Has slot for the transfer roller assembly

14

C8519-69033 Fuser Assembly Fuser Assembly - Bonds toner to paper with heat - For 100V to 127V Operation

14

C8519-69036 Fuser Assembly Fusing Assembly - Bonds toner to paper with heat - For 220V to 240V OperationFusing Assembly - For 220 VAC to 240 VAC - Bonds toner to paper with heat

15

RG5-5717-020CN Contact Toner cartridge contact assembly

16

RS6-2299-000CN Spring Shutter arm spring - Provides tension for shutter arm

17

RB2-5639-000CN Arm Shutter arm for HP LaserJet M9040 MFP

18

RB2-5640-000CN Shutter Laser shutter - Cartridge shutter actuator - Piece that opens cartridge shutter as it is inserted into the printer

19

RS6-2296-000CN Spring Laser shutter spring - Provides tension for laser shutter

2

RB2-5515-000CN Rail Front Fusing Rail

3

RB2-5516-000CN Rail Rear Fusing Rail

4

RB2-5518-020CN Mount Rear fusing assembly mount

5

RB2-5523-000CN Contact Fuser electrical contact leaf spring

7

RG5-5724-050CN Holder Fuser connector holder assembly

8

RG5-8025-000CN Cable Cable assembly - Fuser power cable

9

RS5-0708-000CN Gear 21 tooth gear for HP LaserJet M9040 MFP

Printer parts diagram for: RG5-5651-030CN

RG5-5651-030CN is represented by #11 in the diagram below.
