Lexmark parts list for 20T4000 Optra T616

56P2387 ADF - ADF Optical Assembly

99A0349 Arm - Arm, transfer roll assembly right

99A0405 Arm - Pick arm assembly

99A0448 Arm - Arm, paper out 250-sheet

99A1054 Arm - Pick Arm Assembly

99A1530 Arm - Pick Arm Assembly (500) 212/414/616/21n/41b/41l/41e/61n

99A1578 Arm - Transfer roll left Arm

99A1645 Arm - Arm, paper out 500-sheet tray

99A1646 Arm - Arm assembly, pivot

56P2177 Assembly - Assembly, complete ADF

56P2391 Assembly - Assembly, Lower ADF

56P2581 Assembly - Assembly, Upper ADF

99A0231 Bail - Bail, support

56P2113 Base - Base, ADF assembly

99A1636 Base - Base, 500-sheet tray

99A1638 Base - Base, 250-sheet option

99A0143 Bearing - Bearing, Hot Roll

99A1621 Bearing - Bearing, BUR

56P2383 Belt - Belt, CCD Optical Assembly

56P2397 Belt - Belt, Flatbed CCD Optical Assembly

99A0328 Belt - Belt, Motor 114 Gear

99A0484 Belt - Belt, gear drive

99A1820 Belt - Belt, 185G

99A0491 Bracket - Bracket, stack limiter

99A0679 Bracket - Bracket, 250-sheet frame retention

99A1667 Bracket - Bracket, 500-sheet tray retention

99A1879 Bracket - Bracket, level sensor

99A0150 Bushing - Bushing, Hot Roll

99A0438 Bushing - Bushing, drive roll

99A1555 Bushing - Bushing, charge roll

13A0296 Cable - Cable, Twinax

13A0297 Cable - Cable, Coax 9 pin-to-BNC

40X3257 Cable - Cable, HCIT-14 pin flex

56P0162 Cable - Cable, parallel 1284 C-B adapter

56P0559 Cable - Cable, RJ45 with Toroid

56P1101 Cable - Parallel 1284 A-C (6) Cable

56P1499 Cable - Cable, IEEE 1394, 180mm, 7 inch

56P2050 Cable - Cable, ADF to flatbed

56P2170 Cable - Cable, user interface, 7-pin

56P2171 Cable - Cable, user interface, 14-pin

56P2172 Cable - Cable, user interface, 15-pin

56P2396 Cable - ADF CCD Cable, 6P+14P

56P2398 Cable - Cable, Flatbed CCD Optical

56P2399 Cable - Cable, Operator Panel

99A0247 Cable - Cable, Hysnc

99A0250 Cable - Cable, Mirror Motor

99A0255 Cable - Cable, main drive motor

99A0256 Cable - Cable, Integrated Tray

99A0257 Cable - Cable, Auto Connect Top

99A0281 Cable - Cable, tray autoconnect

99A0282 Cable - Cable, tray autoconnect

99A0310 Cable - Cable, Auto Connect Top

99A0311 Cable - Cable, Auto Connect Bottom

99A0385 Cable - Cable, auto connect front

99A0576 Cable - Cable, Front Harness

99A0577 Cable - Cable Ties Parts Packet (10 each)

99A0684 Cable - Cable, HCIT-14 pin flex

99A0889 Cable - Cable, laser

99A1554 Cable - Fuser Cable, AC

99A1573 Cable - Cable, Fuser DC EP Autoconnect to Engine Board

99A1575 Cable - Cable, Fuser AC EP Autoconnect to LVPS

99A1593 Cable - Cable, Smart Cartridge

99A1612 Cable - Cable, deflector

99A1632 Cable - Cable, Auto Connect Bottom

99A1648 Cable - Fuser Cable, DC

99A1673 Cable - Cable, D.C. Motor Tach

12A5745 Cartridge - Optra T Black Toner Cartridge (12A5745), High Yield

12A5840 Cartridge - 12A5840 Black Toner Cartridge Return Program

12A5845 Cartridge - 12A5845 Black Return Program Toner Cartridge, High Yield

12A5849 Cartridge - 12A5849 Black Toner Cartridge for Label Applications, High Yield Return Program

12A5850 Cartridge - Cartridge Standard Yield, 25,000 pages

12A6844 Cartridge - Cartridge High Yield, 25,000 pages

24B2537 Cartridge - Cartridge High Yield, 25,500 pages

99A1597 Clamp - Clamp, Fuser Cable AC/DC

99A0260 Clip - Clip, cable

99A0267 Clip - Retainers, Clips Parts Packet

99A0346 Clip - Clip, EMC Six Finger

99A0490 Clip - Clip, reference ground

99A1541 Clip - Clip, external ground

99A0393 Clutch - Clutch, restraint/gear

99A0816 Contact - Contact, Smart Cartridge Ground

99A1538 Contact - Contact, RSF Ground

99A1596 Contact - Contact, LSF Ground

99A0815 Contacts - Contacts, Smart Cartridge

56P1264 Controller - Controller, Card Assembly (all countries except Australia/New Zealand)

56P1265 Controller - Controller Card Assembly (Australia/New Zealand)

56P2116 Controller - Card assembly, ADF controller

99A1957 Controller - Controller Board Assembly 616

99A0564 Coupler - Coupler, Gear #55

56P1802 Cover - ADF and Document Cover Assembly

56P2048 Cover - Cover, ADF upper

56P2594 Cover - ADF Base and Document Cover

56P2595 Cover - ADF Access Cover with roller

56P2596 Cover - Cover, ADF Upper

99A0088 Cover - Cover, backup tray

99A0232 Cover - Cover, right

99A0408 Cover - Cover, INA Flat (Blank)

99A1280 Cover - Top Cover Assembly, Movable 500 Duplex

99A1503 Cover - Hinge Assembly, Upper Front Cover

99A1505 Cover - Cover, Right Side

99A1507 Cover - Cover assembly, Laser 500 Output

99A1508 Cover - Cover, Fuser Wick Assembly

99A1510 Cover - Cover, Left Door

99A1511 Cover - Cover assembly, lower front

99A1512 Cover - Cover, redrive cap

99A1595 Cover - Cover, Smart Cartridge Contact

99A1603 Cover - Cover, Fuser Assembly with Thermistor, Thermal Fuse and RH Fuser Lamp Contact Assembly

99A1658 Cover - Cover, fuser wiper cavity

99A1674 Cover - Cover, System Board

99A1679 Cover - Top Cover Assembly, Fixed 500 Duplex

99A1696 Cover - Cover, top

99A1697 Cover - Cover, right side

99A1698 Cover - Cover, left side

99A1966 Cover - Fuser Cover Assembly

99A0312 Deflector - Actuator Assembly, Deflector

99A1525 Deflector - Deflector, upper PF

99A1608 Deflector - Deflector Assembly, MPT

99A1665 Deflector - Deflector, base 500

99A1850 Deflector - Deflector, inner

99A0655 Door - Door assembly, front

99A1534 Door - Door Assembly, Redrive 500

99A1714 Door - Door, rear access

56P0556 Drawer - 500-sheet Drawer, complete assembly

99A1143 Drawer - 250-Sheet Drawer, complete assembly

56P1148 Drive Assembly - Drive Assembly, Hard Disk

99A0276 Drive Assembly - Drive roll assembly

99A0337 Drive Assembly - Main Drive Assembly

99A1533 Drive Assembly - Redrive Assembly, Inner 500

99A1544 Drive Assembly - Developer drive assembly

99A1857 Drive Assembly - Deflector, upper redrive

99A0867 Duct - Duct, Main Body

99A1516 Duct - Duct, 500 Left Stacker

56P1416 Duplexer - 500-sheet Duplex Unit complete assembly

99A0049 Fan - Fan, Auxiliary

99A0308 Fan - Fan, Cooling Duplex

99A0803 Fan - Fan, Main

99A0071 Feeder - Multipurpose feeder Arm assembly

99A1144 Feeder - 2000-Sheet High Capacity Feeder (Letter), complete assembly

99A1145 Feeder - Envelope Feeder, complete assembly

99A1531 Feeder - Multipurpose feeder lower deflector

99A1974 Feeder - Board assembly, Envelope Feeder electronic control

99A0126 Finger - Finger, autosize

99A0084 Flag - Flag, MPT paper out

99A0487 Flag - Flag, envelope out sensor

99A1580 Flag - Flag, output paper level

99A1613 Flag - Flag, output paper level

99A1616 Flag - Flag, Paper Out 500 Tray

56P2382 Flatbed - Flatbed Bottom Assembly

56P2392 Flatbed - Flatbed CCD Optical Assembly

56P2394 Flatbed - Flatbed Bottom Assembly

56P2541 Frame - Fan with Main Board Frame Assembly

56P2592 Frame - ADF Frame

99A0125 Frame - Frame assembly, right side

99A0137 Frame - Frame assembly, left side

99A0445 Frame - Stud assembly, 250-sheet frame

99A0906 Frame - Frame assembly, left side

99A0907 Frame - Frame assembly, right side

99A1514 Frame - Left Side Frame

99A1517 Frame - Frame Extension, Left 500 Internal

99A1518 Frame - Frame Extension, Right 500 Internal

99A1535 Frame - Right side frame

99A1540 Frame - Nut plate, frame extension

99A1693 Frame - Main Frame Assembly 500 Duplex

99A1702 Frame - Stud assembly, 500 frame

99A1833 Frame - Frame, EP Module

99A1897 Frame - Frame, EP Module service level B

99A1903 Frame - Outer Frame Assembly, 500 Duplex

99A0191 Fuse - Fuse, .8A SB

99A0205 Fuse - Fuse, 220 V ac

99A0215 Fuse - Fuse, 110 V ac LVPS

99A1585 Fuser Assembly - Fuser Assembly w/220V 875W Lamp 414/616/41b/41l/41n/61n

99A1977 Fuser Assembly - Fuser Assembly w/115V 875W Lamp 414/616/41b/41l/41n/61n

56P1463 Gear - Hot Roll Gear

99A0148 Gear - Gear, Idler

99A0157 Gear - Gear, Hot Roll

99A0271 Gear - Gears Parts Packet

99A0273 Gear - Gear, bevel

99A0274 Gear - Gear, feed (drive) roll

99A0317 Gear - Gear, Duplex Bevel

99A0325 Gear - Gear, Pass Thru Idler

99A0954 Gear - Bevel Gear with grease packet washer

99A1520 Gear - Gear, Upper Redrive

99A1704 Gear - Gear, idler

99A1705 Gear - Gear, idler

99A0801 Gearbox - Gearbox, w/Motor

99A0394 Grease - Grease Nyogel 744

99A1699 Guard - Guard, pass thru sensor

99A1896 Guard - Guard, Gear

56P2045 Guide - Guide, ADF upper

56P2047 Guide - Guide, ADF lower

99A0226 Guide - Guide, paper exit

99A0323 Guide - Paper guide assembly

99A0330 Guide - Guide Assembly, Center Drive

99A0332 Guide - Guide, Center Drive Upper

99A0469 Guide - Deflector Guide

99A1065 Guide - Paper Decurl Guide Assembly

99A1130 Guide - Guide, return RH upper

99A1131 Guide - Guide, Return LH Upper

99A1164 Guide - Guide, Debuckle

99A1550 Guide - Guide Assembly, Lower Exit

99A1579 Guide - Guide, Upper 500 Duplex

99A1591 Guide - Guide, Fuser Entry

99A1672 Guide - Guide Assembly, Paper Decurl

99A1675 Guide - Guide Assembly, Paper

99A1680 Guide - Guide, Return RH Lower 500 Duplex

99A1682 Guide - Guide, LH Lower Return 500 Duplex

99A1691 Guide - Guide, Lower Entry 500 Duplex

99A1694 Guide - Guide, edge

99A1832 Guide - Guide, extension 500-sheet input

99A0459 Hard Drive - Hard Disk, 2.1+ GB

99A0799 Hard Drive - Optra Forms Hard Disk, 2.1+ GB

56P2114 Hinge - Hinge, ADF assembly, right

99A0863 Hopper - Hopper, Integrated Label/Letter

56P2051 Housing - Housing, flatbed upper

56P2375 Housing - Glass Housing Assembly

99A0324 Idler - Idler Assembly, Belt Tension

99A1797 Idler - Idler pulley, belt tension

99A0627 Jumper - Jumper, 2-pin

12G9707 Kit - Service Information and Training Kit

12G9720 Kit - Service Information and Training Kit

12G9782 Kit - Service Information and Training Kit

12G9816 Kit - Service Information and Training Kit

40X4308 Kit - Pick roll assembly (2 per package)

99A0186 Kit - Parts Kit, Erase Lamp/Lens

99A0299 Kit - Cam Follower Assembly Kit Parts Packet

99A0392 Kit - Kit, door switch spring and bumper

99A0512 Kit - Parts kit, charge roll link assembly, left side

99A0513 Kit - Parts kit, charge roll link assembly, right side

99A0585 Kit - Contact Kit Parts Packet

99A0945 Kit - Kit, Paper Stacking Arm

99A1017 Kit - Optra M410, M412 Charge Roll Kit

99A1605 Kit - Kit, cap/stack bails 500-sheet

99A1775 Kit - Kit, Upper Front Cover with Labels

99A1966 Kit - Fuser Cover Assembly

99A1977 Kit - Fuser Assembly w/115V 875W Lamp 414/616/41b/41l/41n/61n

99A1978 Kit - Optra T614, T616 Fuser Maintenance Kit 110-120V

99A1537 Knob - Knob, paper size

99A0007 Label - Label, TLI/ID/serial number-blank

99A0427 Label - Label, envelope orientation icon

99A0725 Label - Oily Fuser Wiper for Label App (T52x, T62x, Optra S, T)

99A0864 Label - Stacking Device, Integrated Label/Letter

99A0865 Label - Stacking Device, Legal Label

99A1812 Label - Label, tray option number

99A1829 Label - Label, tray option number

99A1952 Label - Label, paper size

56P1733 Lamp - Lamp, flatbed

56P2053 Lamp - Lamp assembly, flatbed

56P2393 Lamp - Lamp Inverter Board

99A1547 Lamp - Lamp, 115V 875W CC Gold

99A1548 Lamp - Lamp, 220V 875W CC Silver

99A1639 Lamp - Lamp, 115V 550W CC Green

99A1642 Lamp - Lamp, 220V 550W CC Brown

99A1502 Latch - Latch, Upper Cover

99A1601 Latch - Latch, back restraint

56P2587 Lens - Lens, LCD Display

99A0559 Lever - Lever, Bellcrank Release

99A0567 Link - Link, gear release

56P2590 Lock - Lock, CCD Optical Assembly

99A0702 Lock - Printer stand caster, non-locking

99A0703 Lock - Printer stand caster, locking

99A0705 Lock - Printer stand lock, cam

99A1149 Mailbox - 5-Bin Mailbox, complete assembly

99A1763 Maintenance Kit - Optra T614, T616 Fuser Maintenance Kit 220-240V

99A1842 Maintenance Kit - Optra T614, T616 Fuser Maintenance Kit 220-240V with wider transfer roll

99A1978 Maintenance Kit - Optra T614, T616 Fuser Maintenance Kit 110-120V

99A1979 Maintenance Kit - Optra T614, T616 Fuser Maintenance Kit 110-120V with wider transfer roll

12G3794 Manual - Optra T61x Service Manual

56P0694 Memory - 4MB SDRAM DIMM (PC 100)

56P0695 Memory - 8MB SDRAM DIMM (PC100)

56P0696 Memory - 16MB SDRAM DIMM (PC100)

56P0698 Memory - 64MB SDRAM DIMM (PC100)

99A1757 Memory - 2MB Flash DIMM

99A1758 Memory - 4MB Flash DIMM

99A1759 Memory - 8MB Flash DIMM

99A1774 Memory - 16MB Flash DIMM

99A1886 Memory - Traditional Chinese Font DIMM

56P1731 Module - Flatbed Module

56P1800 Module - Flatbed Module

56P2063 Motor - Motor, ADF drive

56P2384 Motor - Motor, CCD Optical Assembly

56P2385 Motor - ADF Motor/Sensor Card

56P2388 Motor - ADF Motor/Sensor Card

99A0321 Motor - Motor Assembly, DC Drive

99A0382 Motor - Motor, stepper DC

99A1819 Mounting - Mounting, frame assembly

12G1695 Network - MarkNet N2001e Ethernet 10/100BaseTX internal print server

99A0566 Nut - Nut, Paper Reference Adjustment

56P2049 Pad - 5500 MFP Option Pick Rollers and Pad

99A0058 Pad - Pad, Mounting

99A0120 Pad - Restraint Pad

99A0113 Pan - Pan, Drip ITC

99A0434 Pan - Pan, System Board Drip

99A0899 Pan - Pan, Motor Drip

99A1522 Pan - Pan, Center Assembly

56P1806 Panel - Kit assembly, Operator Panel Conversion

56P2052 Panel - Panel assembly, user interface

56P2376 Panel - Operator Panel Assembly

99A1501 Panel - Operator Panel Assembly

56P0161 PC Board - RS-232-C Serial/Parallel 1284-C Interface Card

56P0314 PC Board - Board, System with Jumper 250/500 Duplex

56P0557 PC Board - Card assembly, tray

56P0588 PC Board - Engine Board Assembly 616/61n

56P2057 PC Board - Card assembly, main scanner

56P2377 PC Board - Board, Main Scanner Control

56P2395 PC Board - Board, Main Scanner Control

56P2589 PC Board - Operator Panel Card Assembly

99A0128 PC Board - Board, input tray (ITC)

99A0923 PC Board - USB/Parallel 1284-C Interface Card

99A1553 PC Board - Board Assembly

99A1806 PC Board - Card assembly, 2000 option control

99A1878 PC Board - Engine Board Assembly 616/61n

99A0082 Plate - Plate Assembly, MPT

99A0121 Plate - 250-sheet tray wear plate

99A0124 Plate - Plate, snap-in

99A0277 Plate - Wear plate, pass thru

99A1583 Plate - Plate, 500-sheet tray wear

99A1588 Plate - Transfer plate assembly

99A1750 Plate - Wear plate, pass thru

99A0834 Plunger - Plunger, Overstress Smart Cartridge

1339537 Power Cord - Power cord; 1.8 m, 6 ft. UK, Ireland, Africa, Middle East, Pakistan, Cyprus, Malaysia, Singapore (HV)

1339538 Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Europe, Middle East, Indonesia, Africa

1339539 Power Cord - Power cord;1.8 m, 6 ft. Israel

1339540 Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Switzerland

1339541 Power Cord - Power cord; 1.8 m, 6 ft. South Africa, Botswana, Lesotho, Namibia, Pakistan

1339542 Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Chile, Italy, Uruguay

1339543 Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Denmark

1339544 Power Cord - Power cord;2.5 m, 8 ft. Straight, Argentina (HV)

1339545 Power Cord - Power cord;2.5 m, 8 ft. Right angle, Argentina (HV)

1342514 Power Cord - Power cord;2.5 m, 8 ft. Right angle, US, Canada, Latin America (LV)

1342530 Power Cord - Power cord;2.5 m, 8 ft. Right angle, Europe, Middle East, Indonesia, Africa (HV)

1342534 Power Cord - Power cord;2.5 m, 8 ft. Right angle, Chile (HV), Italy, Uruguay

1342536 Power Cord - Power cord; 2.5 m, 8 ft. Right angle, Australia, New Zealand (HV)

1374067 Power Cord - Power cord; 2.5 m, 8 ft. Right angle, Peru (HV), US

40X0255 Power Cord - Power cord 2.5 m 8 ft. Right angle Argentina Paraguay Uruguay

43H5248 Power Cord - Power cord;2.5 m, 8 ft. Right angle, US, Canada, Latin America (LV)

43H5249 Power Cord - Power cord; 1.8 m, 6 ft. Right angle, US, CA, Latin America

43H5544 Power Cord - Power cord;2.5 m, 8 ft. Straight, PR China

99A0214 Power Supply - LVPS, 110 V ac

99A1823 Power Supply - High Voltage Power Supply 010/212/414/616/01n/21n/61n

99A1944 Power Supply - HVPS, 220 V ac

99A1873 Printhead - Printhead Assembly, 616/61n

56P2591 Pulley - Idler Pulley, CCD Optical Assembly

99A0208 Pulley - Pulleys Parts Packet

99A0329 Pulley - Pulley, Main Drive 96/54 Gear

99A2093 Restraint - Restraint, back 500-sheet tray

99A0142 Retainer - Retainer, Hot Roll Bearing

99A0144 Retainer - Retainer, Backup Roll Bearing

99A0240 Retainer - Retainers Parts Packet

99A0404 Retainer - Retainers Parts Packet

99A0450 Retainer - Retainer, roller

99A1594 Retainer - Retainer, cable

40X4308 Roller - Pick roll assembly (2 per package)

56P2061 Roller - Roller, input feed

56P2062 Roller - Roller, output feed

99A0039 Roller - Roller, developer support

99A0070 Roller - Pick roll assembly

99A0076 Roller - Pick roll assembly

99A0079 Roller - Tray assembly, backup roller

99A0086 Roller - Roller, backup

99A0158 Roller - Backup Roll, CBM 28 mm

99A0167 Roller - Roller, Redrive Idler

99A0278 Roller - Bellcrank, roller release

99A0451 Roller - Roll, skewed backup

99A0488 Roller - Roller, Support

99A1015 Roller - Transfer roll assembly

99A1129 Roller - Roller, Duplex Pass Thru

99A1549 Roller - Hot Roll

99A1600 Roller - Bellcrank, Backup Roll

99A1631 Roller - Exit Roll Assembly

99A1664 Roller - Bellcrank, roller release

99A1706 Roller - Tray assembly, drive roller

99A1707 Roller - Tray assembly, drive roller

99A1831 Roller - Transfer roll assembly with wider roll

99A0073 Screw - Screw, damper

99A0075 Screw - Screw, socket set M4X5 mm

99A0234 Screw - Screws Parts Packet

99A0263 Screw - Screws Parts Packet

99A0269 Screw - Screw, Washer,Nut Parts Packet

99A0413 Screw - Screws Parts Packet

99A0426 Screw - Screws Parts Packet

99A0492 Screw - Screw, Paper Reference Adjustment

99A0675 Screw - Screws Parts Packet

99A1633 Screw - Screws Parts Packet

99A1649 Screw - Screw, Fuser Mounting

99A1953 Screw - Screw, Reference Ground Clip

56P2060 Sensor - Sensor, ADF paper present

56P2065 Sensor - Sensor assembly, ADF paper feed

56P2389 Sensor - ADF Paper Feed Sensor

99A0053 Sensor - Sensor, Input

99A0060 Sensor - Sensor, Paper Out Internal Tray

99A0078 Sensor - Sensor, MPF paper out

99A0138 Sensor - Sensor, Standard Bin Level

99A0288 Sensor - Sensor, pass thru

99A0341 Sensor - Sensor, Exit - Optical

99A0350 Sensor - Sensor, paper level

99A0466 Sensor - Sensor, Toner Cartridge Level

99A0485 Sensor - Sensor, envelope pass thru

99A1551 Sensor - Sensor, exit

99A1651 Sensor - Sensor, Narrow Media

99A1676 Sensor - Sensor, Input Optical 500 Duplex

12G3633 Service Parts - Optra T scanner shelf

56P0159 Service Parts - Coax/Twinax Adapter for SCS

56P1435 Service Parts - External Serial Adapter

56P2044 Service Parts - Sub assembly, internal ADF CCD

56P2379 Service Parts - CCD Optical Assembly

56P9934 Service Parts - MarkNet N2000t 4/16 Token Ring internal print server

99A0089 Service Parts - Alignment assembly, Paper Feed

99A0307 Service Parts - Air Plenum

99A0389 Service Parts - Paper weight assembly

99A0446 Service Parts - Aligner assembly, paper

99A0462 Service Parts - Packet grease, IBM #23

99A0467 Service Parts - Parallel 1284-C Adapter

99A0560 Service Parts - Tri-Port Adapter (Serial, LocalTalk and Infrared)

99A0676 Service Parts - Nuts Parts Packet

99A0677 Service Parts - Washers Parts Packet

99A0833 Service Parts - Detack Assembly

99A1031 Service Parts - ImageQuick SIMM

99A1089 Service Parts - SIMM for PRESCRIBE Emulation, Optra T

99A1126 Service Parts - Bar Code SIMM T61x

99A1150 Service Parts - High-Capacity Output Stacker, complete assembly

99A1157 Service Parts - Output Expander, complete assembly

99A1183 Service Parts - Optra T ROM SIMM EC5 533.01

99A1519 Service Parts - Extension, 500 Input

99A1792 Service Parts - Stacker, assembly paper path upper

99A1794 Service Parts - Nuts Parts Packet

99A1852 Service Parts - Packaging, 4069 250/250 printer

99A1853 Service Parts - Packaging, 4069 500/250 printer

99A1854 Service Parts - Packaging, 4069 500/500 printer

99A1855 Service Parts - Packaging, 4069 500/500 plus 500

99A1859 Service Parts - ImageQuick TIFF SIMM

99A1884 Service Parts - SIMM for IPDS

99A0074 Shaft - Bushing, pick roll shaft

99A0122 Shaft - Shaft assembly, drive roller

99A0136 Shaft - Shaft, Developer Drive

99A0185 Shaft - Shaft, transfer pivot

99A0197 Shaft - Shaft, drive rear

99A0272 Shaft - Drive Shaft 250-sheet

99A0279 Shaft - Bearing, drive shaft

99A0280 Shaft - Bearing, drive shaft low

99A0316 Shaft - Shaft, Duplex Drive

99A0334 Shaft - Bushing, Decurl Shaft

99A0369 Shaft - Shaft assembly, exit

99A0384 Shaft - Shaft, drive pressure roller

99A0447 Shaft - 550- 500-sheet drive Shaft

99A0572 Shaft - Shaft bearing Parts Packet

99A1059 Shaft - Decurl shaft Assembly

99A1569 Shaft - Shaft, power takeoff 500

99A1692 Shaft - Shaft Assembly, Drive 3 Roll 500 Duplex

99A1695 Shaft - Shaft Assembly, Drive 2 Roll 500 Duplex

99A0206 Shield - Shield, Outer 2 slot

99A0549 Shield - Shield, ESD assembly with label

99A1546 Shield - Shield, gear

99A1566 Shield - Engine Board Shield Assembly

99A1571 Shield - Shield, Inner Assembly, 2 slot 212/414/616/21n/41b/41l/41e/61n: 2 o Cover, INA Blank

99A1598 Shield - Shield, Fuser Board

99A1610 Shield - Shield, Serial Blank

99A1611 Shield - Shield Ethernet (blank)

99A1617 Shield - Interconnect Board Assembly 212/414/616/41b/41l/41n/21n/61n: 2 Slot with shield

99A2094 Shield - Shield, Outer 2 slot

99A1592 Shroud - Shroud, Fan 500

99A0127 Slider - Slider, autosize 250-sheet tray

99A1582 Slider - Slider, autosize 500-sheet

99A0173 Solenoid - Solenoid Assembly, Envelope Conditioner

99A0297 Solenoid - Link, Solenoid

99A2438 Solenoid - Solenoid, MPT

56P1228 Spring - Spring Arm Bellcrank

56P1331 Spring - Parts packet, bellcrank and spring (500)

56P1337 Spring - Parts Packet, bellcrank and spring (250)

56P2034 Spring - Spring Arm Bellcrank (5)

56P2540 Spring - Bellcrank spring - 500-sheet tray

99A0004 Spring - Spring, latch

99A0028 Spring - Spring, tray bias

99A0063 Spring - Switch Activate Spring

99A0081 Spring - Spring assembly, separator

99A0087 Spring - Spring, backup roller

99A0104 Spring - Upper Diverter Spring

99A0181 Spring - Spring, transfer roll left

99A0184 Spring - Spring, transfer roll right

99A0268 Spring - Springs Paper Feed Parts Packet

99A0275 Spring - Power Takeoff Spring

99A0286 Spring - Spring, backup roller

99A0315 Spring - Spring, Duplex Shaft

99A0326 Spring - Spring, Aligner

99A0335 Spring - Spring, Decurl Shaft

99A0400 Spring - Spring, restraint roll shaft

99A0410 Spring - Spring, Backup Roll Bellcrank

99A0419 Spring - Spring, tray bias

99A0489 Spring - Spring, latch return

99A0494 Spring - Spring, cam clutch

99A0556 Spring - Spring, counterbalance

99A0897 Spring - Spring, Redrive Idler

99A1524 Spring - Cartridge load spring

99A1689 Spring - Spring clutch assembly

99A1924 Spring - Spring, cartridge hold down

99A1929 Spring - Bellcrank spring - 250-sheet paper tray

99A1930 Spring - Spring, Bellcrank Internal 500

99A0704 Stand - Printer stand grommet, wire

99A0706 Stand - Printer stand storage shelf

99A0710 Stand - Printer stand filler, rear top piece

99A0711 Stand - Printer stand table assembly, large

99A0712 Stand - Printer stand table assembly, small

99A0919 Standoff - Standoff, Fuser Control Board

99A1902 Standoff - Standoff, Fuser Control Board

56P1279 Strip - Wear strips

56P2059 Strip - Strip, Mylar, paper entry

56P2222 Strip - Strip, Mylar, paper exit

99A0292 Strip - Wear strips

99A0390 Support - Support, slide out

99A1587 Support - Support, Paper

99A1662 Support - Support, left lower stacker

99A1885 Support - DIMM, COS (supports Chinese fonts)

99A1968 Support - Support, right stacker plate

99A0388 Switch - Switch, envelope out

99A1577 Switch - Switch, Cover Open w/Operator Panel Cable Assembly

40X3351 Tray - Tray Option Card assembly

56P1467 Tray - 2000-Sheet Input

56P1732 Tray - ADF Input Tray

56P1803 Tray - Paper Tray

56P2046 Tray - Tray, paper input

56P2716 Tray - Scanner calibration sheet

99A0026 Tray - Tray Bias Arm Assembly

99A0083 Tray - Multipurpose Tray Parts Kit

99A0085 Tray - Tray, backup roller

99A0893 Tray - Restraint, back 250-sheet tray

99A1134 Tray - Tray Assembly, Jam Removal 500 Duplex

99A1536 Tray - 250-sheet Tray, complete assembly

99A1576 Tray - 500-sheet Tray, complete assembly

99A1599 Tray - Tray, Fuser AC Connector

99A1602 Tray - Back Restraint, 500-sheet tray

99A1647 Tray - Rib assembly, 250-sheet special media tray

99A1654 Tray - 250-sheet (UAT) Tray

99A1677 Tray - Base Assembly, w/Tray Bias 500 Duplex

99A1890 Tray - Tray assembly, 250-sheet special media

99A1894 Tray - Restraint, side 250-sheet tray

99A1895 Tray - Restraint, side 500-sheet tray

99A0452 Washer - Washer, Mounting

99A0565 Washer - Washer, Reference Adjustment

Lexmark Optra T616 (20T4000)

Lexmark parts list for 20T4000 Lexmark Optra T616 Printer
