Lexmark parts list for 22B0000 Laser C524

40X1435 Arm - MPF swing arm assembly, C524, C53x

40X3607 Arm - Pick arm roll

40X1401 Belt - Transfer belt assembly, C52x

40X1415 Bezel - Outer Bezel

40X1448 Bezel - Inner Bezel, C524, C524n, C524dn

40X1835 Bracket - Front door brackets

40X1430 Cable - Cables Parts Packet, C52x

C5220CS Cartridge - Cyan Toner Cartridge (C5220CS), Return Program

C5220MS Cartridge - Magenta Toner Cartridge (C5220MS), Return Program

C5220YS Cartridge - Yellow Toner Cartridge (C5220YS), Return Program

C5222CS Cartridge - Cyan Toner Cartridge (C5222CS)

C5222KS Cartridge - Yield black toner

C5222MS Cartridge - Magenta Toner Cartridge (C5222MS)

C5222YS Cartridge - Yellow Toner Cartridge (C5222YS)

C5240CH Cartridge - high yield toner cartridge - cyan - 5,000 pages based on approximately 5% covera

C5240KH Cartridge - toner cartridge - black - 8000 pages at 5% coverage

C5240MH Cartridge - high yield toner cartridge - magenta - 5,000 pages based on approximately 5% cov

C5240YH Cartridge - high yield toner cartridge - yellow - 5,000 pages based on approximately 5% cove

C5242CH Cartridge - Cyan Toner Cartridge (C5242CH), High Yield

C5242KH Cartridge - Black Toner Cartridge (C5242KH), High Yield

C5242MH Cartridge - Magenta Toner Cartridge (C5242MH), High Yield

C5242YH Cartridge - Yellow Toner Cartridge (C5242YH), High Yield

C53030X Cartridge - Cartridge Standard Yield, 20,000 pages

40X1428 Contact - Transfer contact assembly

40X1412 Cover - Top access cover assembly (non-network), C524

40X1413 Cover - Front access door cover assembly (non-duplex), C52xn, C524

40X1421 Cover - Top cover camshaft assembly

40X1422 Cover - Exit tray cover

40X1425 Cover - Right cover

40X1426 Cover - Left cover

40X1427 Cover - Rear cover

40X3613 Cover - Top cover camshaft assembly

40X1444 Deflector - Deflector assembly, C52x

40X1418 Door - Front door assembly, C520n, C522n, C524n

40X1420 Door - Front Door Parts Packet, C52x

40X1439 Drawer - 500-Sheet Drawer, complete assembly C522, C524

40X1409 Drive Assembly - EP Drive assembly, C52x

40X1455 Flash Card - 64MB Flash Card

40X1400 Fuser Assembly - 110v fuser unit

40X1402 Fuser Assembly - 220v fuser unit

40X1432 Gear - Bump aligner gear Parts packet

40X1401 Kit - Transfer belt assembly, C52x

40X3569 Kit - C52x, C53x Fuser Maintenance Kit 110-120V

40X3570 Kit - Lexmark SP/LE Fuser Unit Optra C530/532/534

7377018 Kit - Relocation packaging kit, C52x, C53x

7377200 Kit - Relocation packaging kit Drawers

C53030X Kit - Cartridge Standard Yield, 20,000 pages

40X1403 Maintenance Kit - C52x Fuser Maintenance Kit 100V

40X3569 Maintenance Kit - C52x, C53x Fuser Maintenance Kit 110-120V

40X3570 Maintenance Kit - Lexmark SP/LE Fuser Unit Optra C530/532/534

40X3571 Maintenance Kit - C52x, C53x Fuser Maintenance Kit 100V

12G9601 Manual - C52x Service Manual

12G9669 Manual - C52x, C53x Service Manual

40X1433 Motor - Bump aligner motor

40X4217 Network - System non-network card, C524

40X1414 Panel - Operator panel Assembly, C52x

40X1407 PC Board - System non-network card, C524

40X1410 PC Board - Smart chip card, C52x

40X1564 PC Board - 32MB Flash Card

40X1565 PC Board - 64MB Flash Card

40X1445 Plate - Ground contact plate, C52x

1339548 Power Cord - Power cord;1.8 m, 6 ft. Straight, Brazil (LV)

40X0277 Power Cord - Power cord;1.8 m, 6 ft. Straight, Brazil

40X3609 Power Cord - Power cord 2.5 m 8 ft. Straight Japan

40X3610 Power Cord - Power cord; 1.8 m, 6 ft. Straight, Taiwan

40X3611 Power Cord - Power cord 1.8 m 6 ft. Straight Brazil (LV)

40X1406 Power Supply - Low Volt Power supply, 115/230 V, C52x

40X1411 Power Supply - High volt power supply, C52x

40X3574 Power Supply - Low Volt Power supply, 115/230 V, C53x

40X1417 Printhead - Printhead assembly, C52x

40X2167 Printhead - Printhead assembly, C52x

40X1438 Roller - Pick arm roll

40X1431 Screw - Screws Parts Packet

40X1416 Sensor - Toner level sensor

40X1405 Service Parts - Paper pick mechanism assembly, C52x

40X1508 Service Parts - 128MB DDR-DRAM

40X3619 Shaft - Top cover camshaft assembly

40X1434 Spring - Contact Springs Parts Packet

40X1446 Spring - Right bellcrank assembly with spring

40X1447 Spring - Left bellcrank assembly with spring

40X1429 Support - System card support shield, C52x

40X1436 Switch - Front door 5V interlock Switch

40X1437 Switch - Top access door 24V interlock switch

40X1404 Tray - MPF paper tray assembly, 250-sheet, C524

40X1423 Tray - 500-sheet Tray assembly, C522, C524

Lexmark Laser C524 (22B0000)

Lexmark parts list for 22B0000 Lexmark Laser C524 Printer
