Lexmark parts list for 25A0001 Laser W840N

40X0587 Actuator - Media out actuator

40X0622 Actuator - PC cartridge shutter actuator

40X0659 Belt - Exit 1 drive belt

40X0661 Belt - Drive belt flange

40X0878 Bushing - 8 mm bushing

40X0880 Bushing - Bushing 6 mm

40X0952 Bushing - Bushing 6 mm

40X1386 Bushing - Bushing 6 mm (transport roll rear)

40X1388 Bushing - Bushing 8 mm

40X0250 Cable - 9-pin to Twinax cable

40X0251 Cable - 9-pin to Coax (BNC) cable

40X0252 Cable - 9-pin to 9-pin cable

40X0555 Cable - Operator panel cable assembly

40X0565 Cable - Cable hookup door kit

40X0597 Cable - MPF unit cable assembly

40X0637 Cable - Multi-connector cable assembly 1

40X0650 Cable - Exit 1 sensor cable assembly

40X0674 Cable - Media feed unit cable assembly

40X0675 Cable - MPF hookup cable assembly

40X0676 Cable - Media size switch cable assembly

40X0677 Cable - RIP card cable assembly

40X0678 Cable - Printhead cable assembly

40X0679 Cable - Exit interface cable assembly

40X0680 Cable - Multi connector cable assembly 2

40X0681 Cable - Fuser AC cable assembly

40X0682 Cable - Multi connector cable assembly 3

40X0683 Cable - Interlock switch cable assembly

40X0684 Cable - Main switch cable assembly

40X0685 Cable - Dual drive motor cable assembly

40X0686 Cable - RFID sensor cable assembly

40X0788 Cable - Duplex cable kit

40X1367 Cable - Parallel cable packaged (3 m)

40X1368 Cable - USB cable packaged (2 m)

40X0642 Cards - RIP card assembly

40X0618 Cartridge - PC cartridge shutter link

W84020H Cartridge - W84020H Black Toner Cartridge

40X0948 Clip - Parts Packet e-clip

40X0591 Clutch - Feed roll one-way clutch kit

40X0593 Clutch - Separation roll friction clutch kit

40X0626 Clutch - Registration clutch

40X0629 Clutch - Transport clutch assembly

40X0967 Clutch - Media tray lift one-way clutch and gear

40X8459 Connector - USB connector

40X0550 Cover - Left lower cover

40X0551 Cover - Front left cover

40X0552 Cover - Top rear cover

40X0558 Cover - Top cover assembly

40X0562 Cover - Front inner cover

40X0563 Cover - Right upper cover

40X0564 Cover - Right lower cover

40X0566 Cover - Rear motor cover

40X0567 Cover - Rear lower cover (110V)

40X0568 Cover - Option hookup cover

40X0574 Cover - Media tray front cover

40X0599 Cover - Multipurpose feeder front cover

40X0600 Cover - Multipurpose feeder rear cover

40X0655 Cover - Standard exit 1 top cover

40X0672 Cover - Rear RIP card cover

40X0787 Cover - Duplex left cover

40X0798 Cover - Left cover

40X0799 Cover - Front cover

40X0800 Cover - Rear cover

40X0801 Cover - Right cover kit

40X0955 Cover - Rear lower cover (220V)

40X0972 Cover - USB function removal cover (25)

40X2395 Cover - USB function removal cover

40X7539 Cover - USB connector cover

40X0559 Door - Printer front door assembly

40X0560 Door - Front door magnetic catch

40X0612 Door - Left lower door assembly (assembled)

40X0620 Door - Left door assembly (assembled)

40X0780 Duplexer - Duplex unit assembly (assembled)

40X0640 Fan - Fuser cooling fan

40X0643 Fan - PC cartridge cooling fan

40X0807 Fan - Exit 2 cooling fan

40X0603 Feeder - Multipurpose feeder pick roll kit

40X1454 Flash Card - 32MB Flash Card

40X1455 Flash Card - 64MB Flash Card

40X1396 Forms Card - W840 Forms Card (SB fonts)

40X0588 Fuser Assembly - Sensor (fuser exit media out media level bin full media shift HP)

40X0645 Fuser Assembly - Fuser exit actuator kit

40X0646 Fuser Assembly - Fuser assembly 100V (assembled), W840, W850

40X0647 Fuser Assembly - Fuser assembly 110-120V (assembled), W840, W850

40X0648 Fuser Assembly - Fuser assembly 220-240V (assembled), W840, W850

40X5931 Fuser Assembly - Fuser exit sensor assembly

40X0580 Gear - Media tray lift gear kit

40X0585 Gear - Media feed drive gear kit

40X0598 Gear - MPF Idler gear bracket assembly

40X0609 Gear - Vertical drive gear assembly

40X0653 Gear - Exit 1 media shift gear

40X0658 Gear - MPF & transport roll idler gear kit

40X0781 Gear - Duplex drive gear kit

40X0803 Gear - Exit 2 media shift gear

40X0969 Gear - Pick roll idler gear

40X0970 Gear - Pick roll drive gear

40X0971 Gear - MPF feed drive gear kit

40X0973 Gear - MPF feed cam gear kit

40X0571 Guide - Vertical turn mylar guide

40X0572 Guide - Vertical turn guide

40X0576 Guide - Media tray side guide kit

40X0577 Guide - Media tray side guide actuator kit

40X0578 Guide - Media tray end guide kit

40X0579 Guide - Media tray end guide actuator kit

40X0586 Guide - Media feed unit front guide kit

40X0619 Guide - Transfer roll guide assembly

40X0623 Guide - Left door duplex entrance guide

40X0628 Guide - Registration mylar guide assembly

40X0630 Guide - Tray 2 feed-out sensor guide (assembled)

40X0634 Guide - PC cartridge guide assembly

40X0635 Guide - Laser opening guide

40X0638 Guide - Toner cartridge guide kit

40X0783 Guide - Duplex lower guide

40X1392 Guide - Exit 1 media exit guide kit

40X2389 Guide - Output guide

40X0614 Handle - Left lower door handle kit

40X0621 Handle - Left door assembly handle kit

40X0782 Handle - Duplex left door handle kit

40X0795 Handle - Exit 2 left door handle kit

40X2610 Hard Drive - Hard disk with adapter - 40+ GB

40X0613 Hinge - Hinge pin

40X0791 Hinge - Hinge pin (2)

40X0553 Interlock - Switch (door interlock)

40X0610 Interlock - Switch (left door interlock)

40X1390 Interlock - Switch (PC cartridge interlock) kit

40X0594 Kit - Feed unit roll kit

40X0596 Kit - MPF media out actuator kit

40X0605 Kit - MPF transport roll kit

40X0647 Kit - Fuser assembly 110-120V (assembled), W840, W850

40X0654 Kit - Media diverter gate kit

40X0657 Kit - Bin full actuator kit

40X0670 Kit - AC power input socket kit

40X0784 Kit - Duplex wait actuator kit

40X0792 Kit - Duplex media transport pinch roll kit

40X0793 Kit - Duplex media transport roll kit

40X0796 Kit - Media diverter gate kit

40X0806 Kit - Pinch roll kit

40X0808 Kit - Bin full actuator kit

40X0809 Kit - Exit 2 actuator kit

40X0956 Kit - W840, W850 Fuser Maintenance Kit 110-120V

40X0957 Kit - Lexmark W840 Fuser Maintenance Kit 220-240V

40X0958 Kit - W840, W850 Fuser Maintenance Kit 100V

40X1387 Kit - Transport roll kit

7374474 Kit - W840 X850e X852e X854e Repacking Kit

40X0802 Latch - Docking latch kit

40X0790 Lock - Docking lock (2)

40X0956 Maintenance Kit - W840, W850 Fuser Maintenance Kit 110-120V

40X0957 Maintenance Kit - Lexmark W840 Fuser Maintenance Kit 220-240V

40X0958 Maintenance Kit - W840, W850 Fuser Maintenance Kit 100V

12G9602 Manual - W840 Service Manual

12G9604 Manual - W840 Finisher Service Manual

40X1509 Memory - 256MB DDR-DRAM

40X1510 Memory - 512MB DDR-DRAM

40X0582 Motor - Media feed lift motor

40X0639 Motor - Toner add motor assembly

40X0651 Motor - Media shift motor

40X0660 Motor - Dual drive motor assembly

40X0785 Motor - Duplex drive motor kit

40X1377 Network - MarkNet N8030 Fiber Ethernet 100BaseTX

40X0965 Pad - Media tray separation pad

40X0974 Pad - MPF pressure pad kit

40X0554 Panel - Operator panel assembly

40X0290 PC Board - RS-232 Serial Interface Card

40X0291 PC Board - Parallel 1284-B interface card

40X0664 PC Board - Exit interface card assembly

40X0665 PC Board - Engine card assembly

40X0786 PC Board - Duplex controller card assembly

40X0964 PC Board - Interconnect card assembly, W840

40X1393 PC Board - Bar Code Card W840

40X1394 PC Board - Card for PRESCRIBE Emulation, W840

40X1395 PC Board - Lexmark PrintCryption Card W840

40X1397 PC Board - W840 Forms Card (DBCS fonts)

40X1398 PC Board - Card for IPDS and SCS/TNe W840

40X1512 PC Board - Japanese Font Card

40X1513 PC Board - S. Chinese Font Card

40X1515 PC Board - Korean Font Card

40X1564 PC Board - 32MB Flash Card

40X1565 PC Board - 64MB Flash Card

40X2397 PC Board - Card for IPDS and SCS/TNe, W840

40X3214 PC Board - RIP card assembly, EC1, W840

40X4198 PC Board - Card for IPDS and SCS/TNe, W840

40X0269 Power Cord - Power cord 2.5 m 8 ft. Right angle US CA LA

40X0270 Power Cord - Power Cord 2.5 m 8 ft. Straight Japan

40X0273 Power Cord - Power cord 2.5 m 8 ft. Straight Italy Chile Uruguay

40X0274 Power Cord - Power cord 1.8 m 6 ft. Straight Switzerland

40X0276 Power Cord - Power cord 1.8 m 6 ft. Straight Botswana South Africa

40X0277 Power Cord - Power cord;1.8 m, 6 ft. Straight, Brazil

40X0278 Power Cord - Power cord 1.8 m 6 ft. Straight Europe Middle East Indonesia Africa

40X0279 Power Cord - Power cord 1.8 m 6 ft. Straight Denmark

40X0280 Power Cord - Power cord 1.8 m 6 ft. Straight Korea

40X0281 Power Cord - Power cord 1.8 m 6 ft. Straight Taiwan

40X0282 Power Cord - Power cord 1.8 m 6 ft. Straight PR China

40X0286 Power Cord - Power cord 1.8 m 6 ft. Straight UK Ireland Hong Kong

40X0287 Power Cord - Power cord 1.8 m 6 ft. Straight Chile Italy Uruguay

40X0293 Power Cord - Power cord 2.5 m 8 ft. Right angle UK Malaysia Singapore

40X0296 Power Cord - Power cord 1.8 m 6 ft. Straight Australia New Zealand

40X0297 Power Cord - Power cord 1.8 m 6 ft. Straight US Canada Latin America AP

40X4596 Power Cord - Power cord 2.5 m 8 ft. Straight Brazil

40X0662 Power Supply - HVPS

40X0666 Power Supply - LVPS 100/110V

40X0667 Power Supply - LVPS 220V

40X0641 Printhead - Printhead assembly

40X0601 Roller - MPF transport pinch roll assembly

40X0616 Roller - Transfer roll assembly

40X0617 Roller - Transfer roll power contact

40X0625 Roller - Registration roll assembly

40X0949 Screw - Parts Packet Screws

40X0960 Screw - Retaining screws

40X1389 Screw - PC cartridge interlock switch screw

40X0589 Sensor - Sensor (pre-feed tray 2 feed-out ADF registration)

40X0627 Sensor - Sensor (registration)

40X0633 Sensor - Sensor (humidity & temperature)

40X0636 Sensor - Sensor (RFID toner PC cartridge)

40X0644 Sensor - PC cartridge sensor connector

40X5985 Sensor - Sensor assembly

40X0179 Service Parts - Grease, Nyogel 744

40X0248 Service Parts - Coax/Twinax Adapter for SCS

40X0275 Service Parts - Power cord; 2.5 m, 8 ft. Straight, Isreal

40X0288 Service Parts - 40X0288

40X0556 Service Parts - USB connector

40X0581 Service Parts - Media feed unit assembly (assembled)

40X0595 Service Parts - Multipurpose feed unit assembly

40X0631 Service Parts - PC cartridge stop

40X0649 Service Parts - Exit 1 media shift assembly (assembled)

40X0668 Service Parts - Choke coil 220V (220V model only)

40X0673 Service Parts - HCF hookup connector assembly

40X0794 Service Parts - Exit 2 unit assembly (assembled)

40X1391 Service Parts - Exit 1 static eliminator

40X1508 Service Parts - 128MB DDR-DRAM

40X1514 Service Parts - 40X1514

40X2382 Service Parts - 40X2382

40X6000 Service Parts - Multipurpose feed unit assembly

40X0968 Shaft - Media tray lift one-way shaft

40X1381 Shaft - Multipurpose feeder - feed shaft bushing

40X1382 Shaft - MPF feed shaft kit

40X0606 Solenoid - MPF pick solenoid kit

40X0805 Solenoid - Media diverter solenoid kit

40X0590 Spring - Pick roll assembly spring

40X0755 Spring - Multipurpose feeder pickup spring

40X1380 Spring - MPF pressure pad spring

40X0561 Strap - Front door support strap

40X0624 Strap - Left door support strap

40X0789 Strap - Duplex left door support strap

40X0797 Strap - Exit 2 left door support strap

40X0570 Switch - Switch (media size)

40X0663 Switch - Switch (main power)

40X0569 Tray - Media tray catch kit

40X0573 Tray - Media tray assembly Media Tray Assembly 500 Sheet

40X0583 Tray - Tray lift coupling kit

40X0608 Tray - MPF Fold down tray assembly

40X0966 Tray - Media tray separation brush

Lexmark Laser W840N (25A0001)

Lexmark parts list for 25A0001 Lexmark Laser W840N Printer
