Lexmark parts list for 5055-200 Laser C912

56P9507 Actuator - Actuator, paper feed sensor

56P9641 Actuator - Actuator, front cover open switch

56P9784 Actuator - Actuator, paper detection

56P9413 Assembly - Assembly, motor bracket

56P9627 Bearing - Bearing, roller

56P9814 Bearing - Bearing, release

56P9437 Belt - Belt, timing

56P9578 Belt - Belt, face down roller

56P9694 Belt - Transfer belt unit

56P9732 Belt - Belt, power supply

56P9822 Belt - Belt, timing

56P9823 Belt - Belt, timing

56P9745 Box - Box, RIP

56P9389 Bracket - Bracket

56P9455 Bracket - Bracket

56P9469 Bracket - Bracket

56P9508 Bracket - Bracket, ground

56P9612 Bracket - Bracket, front upper

56P9619 Bracket - Bracket, rear upper

56P9621 Bracket - Bracket, fan holder

56P9372 Brush - Brush, static discharge

56P9376 Bushing - Bushing

56P9402 Bushing - Bushing

56P9509 Bushing - Bushing, metal

56P9513 Bushing - Bushing, carrying

56P9575 Bushing - Bushing, face down pinch roller

56P9697 Bushing - Bushing

56P9752 C910 - C910, C912 Fuser 230V

56P9969 C910 - C910, C912 Users Guide

40X3483 Cable - HCF Interface Cable

56P0162 Cable - Cable, parallel 1284 C-B adapter

56P9409 Cable - Cable

56P9428 Cable - Cable

56P9435 Cable - Cable, set switch

56P9436 Cable - Cable

56P9523 Cable - Cable assembly, size sensor

56P9600 Cable - Cable assembly, K13

56P9601 Cable - Cable assembly, K24

56P9602 Cable - Cable assembly, CL13

56P9603 Cable - Cable assembly, CL24

56P9605 Cable - Cable assembly, HDFG

56P9606 Cable - Cable assembly, RSPFG

56P9607 Cable - Cable assembly, LFG

56P9644 Cable - Cable assembly, drive unit sensor

56P9692 Cable - Cable assembly, reg MPF sensor

56P9695 Cable - Cable, turn guide door sensor

56P9696 Cable - Cable assembly, belt thermistor

56P9702 Cable - Cable, belt up/down sensor

56P9703 Cable - Cable assembly, sensor board

56P9704 Cable - Cable assembly, paper remaining sensor

56P9705 Cable - Cable assembly, feeder

56P9706 Cable - Cable, power switch

56P9708 Cable - Cable assembly, duplex connector

56P9711 Cable - Cable, THB drawer

56P9712 Cable - Cable, THB drawer (EMEA)

56P9715 Cable - Cable high voltage power supply board

56P9721 Cable - Cable assembly, drum eraser

56P9730 Cable - Cable assembly, HCF

56P9731 Cable - Cable assembly, finisher

56P9733 Cable - Cable assembly, HCPF interface

56P9736 Cable - Cable, operator panel

56P9738 Cable - Cable assembly, conditioning joint (230 V only)

56P9740 Cable - Cable, conditioning resistor

56P9747 Cable - Cable assembly, power MAC

56P9748 Cable - Cable assembly, MIF

56P9749 Cable - Cable assembly, power RIP

56P9775 Cable - Cable assembly, size sensor

56P9777 Cable - Cable assembly, upper optional drawer

56P9778 Cable - Cable assembly, lower optional drawer

56P9787 Cable - Cable, paper present sensor

56P9795 Cable - Cable, paper present sensor

56P9806 Cable - Cable assembly, paper detection

56P9807 Cable - Cable assembly, duplex interface

56P9479 Cap - Cap

12N0768 Cartridge - 12N0768 Cyan Toner Cartridge

12N0769 Cartridge - 12N0769 Magenta Toner Cartridge

12N0770 Cartridge - 12N0770 Yellow Toner Cartridge

12N0771 Cartridge - 12N0771 Black Toner Cartridge

56P9500 Cassette - Cassette, paper feed

11G0291 Clutch - Paper Feed Clutch

56P9643 Clutch - Clutch, drive unit

56P9663 Clutch - Clutch, belt up/down

56P9681 Clutch - Clutch, registration

56P9639 Connector - Connector, upper

56P9620 Controller - Board, printhead controller-S/N XX-0XXXX

56P9637 Controller - Frame, printhead controller

56P9716 Controller - Cable assembly, 8-pin PH controller

56P9717 Controller - Cable assembly, 18-pin PH controller- S/N XX-0XXXX

56P9718 Controller - Cable assembly, 30-pin PH controller- S/N XX-0XXXX

56P9719 Controller - Cable assembly, 80 pin RIP printer controller

56P9720 Controller - Cable assembly, PH controller power

56P9726 Controller - Cable assembly, printer controller power 1

56P9727 Controller - Cable assembly, printer controller power 2

56P9729 Controller - EPROM, printer controller

56P9739 Controller - Cable assembly, conditioning printer controller

56P9973 Controller - Board, RIP controller (C912)

56P9974 Controller - Board, RIP controller, network (C912)

56P9987 Controller - Board, printhead controller-S/N XX-1XXXX

56P9991 Controller - Cable assembly 48-pin PH controller- S/N XX-1XXXX

56P9992 Controller - Board, printer controller (C912)- S/N XX-1XXXX

56P9554 Core - Core, ferrite

56P9604 Core - Core, ferrite

56P9989 Core - Core, Ferrite-S/N XX-1XXXX

56P4557 Cover - Black photodeveloper Cover

56P9533 Cover - Cover assembly, right side

56P9536 Cover - Cover, left side

56P9537 Cover - Cover, paper feed

56P9538 Cover - Cover, rear

56P9539 Cover - Cover, top

56P9540 Cover - Cover, waste toner bottle

56P9542 Cover - Cover, left front

56P9551 Cover - Cover, adjustment

56P9594 Cover - Cover, eraser

56P9626 Cover - Cover, hook

56P9673 Cover - Cover, electronic

56P9687 Cover - Cover, gear

56P9746 Cover - Cover, RIP box

56P9765 Cover - Cover, front feeder

56P9766 Cover - Cover, left side

56P9767 Cover - Cover, right side A

56P9768 Cover - Cover, rear

56P9769 Cover - Cover, right side B

56P9770 Cover - Cover, right side C

56P9785 Cover - Cover, paper present sensor

56P9797 Cover - Cover, gear

56P9970 Cover - Cover assembly, front (C912)

56P9383 Cushion - Cushion

12N0772 Developer - Lexmark 12N0772 Color Photodeveloper Kit, 3/Pack

12N0773 Developer - Lexmark 12N0773 Black Photodeveloper

56P9622 Fan - Fan, upper right

56P9623 Fan - Fan, upper left

56P9713 Fan - Fan, power supply

56P9750 Fan - Fan, RIP

56P9972 Feeder - Feeder assembly, multipurpose

56P9417 Flange - Flange

56P9914 Flash Card - 16MB Flash DIMM

56P9928 Flash Card - Optra Forms 4MB Flash DIMM

56P9929 Flash Card - Optra Forms 8MB Flash DIMM

56P9503 Foot - Foot, rubber

56P9370 Frame - Frame, guide

56P9374 Frame - Frame, C guide

56P9381 Frame - Frame, B guide

56P9506 Frame - Frame, paper feed

56P9591 Frame - Frame, upper

56P9629 Frame - Frame, link

56P9646 Frame - Frame, sub

56P9664 Frame - Frame, paper feed

56P9680 Frame - Frame assembly, registration

56P9682 Frame - Frame assembly, carrying

56P9684 Frame - Frame assembly, F1 sub

56P9685 Frame - Frame assembly, F2 sub

56P9971 Frame - Frame assembly, MPF

40X1517 Fuse - Fuse, thermal (230V only)

56P9943 Fuse - Fuse, thermal (230 V only)

56P9751 Fuser Assembly - C910, C912 Fuser 120V

11G0297 Gear - Carrying Gear

11G0422 Gear - Gear, Idler

11G0423 Gear - Gear, S37xs24

56P9397 Gear - Gear, Z20

56P9456 Gear - Gear, Z46/Z33

56P9457 Gear - Gear, Z90/Z14

56P9458 Gear - Gear, Z25/Z20

56P9527 Gear - Gear, idler

56P9771 Gear - Gear, feeder C

56P9772 Gear - Gear, feeder D

56P9773 Gear - Gear, feeder E

56P9817 Gear - Gear, carrying roller

56P9980 Guard - Guard, rack

11G0199 Guide - Wire Guide

40X2777 Guide - Lock guide

40X3484 Guide - Guide, HCF

56P9418 Guide - Guide, stack

56P9515 Guide - Guide, upper cassette

56P9518 Guide - Guide, lower left cassette

56P9519 Guide - Guide, lower right cassette

56P9566 Guide - Guide assembly, face-down

56P9584 Guide - Guide assembly, turn

56P9671 Guide - Guide, cable

56P9672 Guide - Guide, cable

56P9674 Guide - Guide assembly, fuser entrance

56P9788 Guide - Guide, HCF

56P9789 Guide - Guide, turn

56P9826 Guide - Guide, front side

56P9827 Guide - Guide, rear side

56P9979 Guide - Guide, stop

56P9387 Handle - Handle, jam

56P9394 Handle - Handle

56P9520 Handle - Handle, waste bottle cam

56P9616 Handle - Handle, upper opening

56P9669 Handle - Handle, lock

40X2610 Hard Drive - Hard disk with adapter - 40+ GB

56P9932 Hard Drive - Optra Forms hard disk, 5+GB w/adapter

56P9942 Hard Drive - Hard drive mounting kit

56P9982 Hard Drive - Hard Disk, 20GB with/Adapter (formatted)

56P9593 Holder - Holder, rear printhead

56P9608 Holder - Holder, front HSP

56P9611 Holder - Holder, front printhead

56P9638 Holder - Holder, cable

56P9792 Holder - Holder, roller

56P9615 Hook - Hook, middle

56P9617 Hook - Hook, left

56P9618 Hook - Hook, right

56P9625 Hook - Hook, right link

56P9630 Hook - Hook, left link

56P9477 Housing - Housing, caster

56P9555 Housing - Housing, upper operator panel

56P9556 Housing - Housing, lower operator panel

56P9737 Insulator - Insulator, sheet

12G9816 Kit - Service Information and Training Kit

12N0772 Kit - Lexmark 12N0772 Color Photodeveloper Kit, 3/Pack

12N0773 Kit - Lexmark 12N0773 Black Photodeveloper

56P9751 Kit - C910, C912 Fuser 120V

7370516 Kit - Relocation packaging kit

56P9475 Knob - Knob, caster

56P9821 Knob - Knob, paper re-feed

56P9544 Label - Label, MPT

56P9545 Label - Label, operator guide

56P9595 Lamp - Lamp, M erase

56P9596 Lamp - Lamp, C erase

56P9597 Lamp - Lamp, Y erase

56P9598 Lamp - Lamp, K erase

56P9366 Lever - Lever, B

56P9521 Lever - Lever, size sensor

56P9781 Lever - Lever, clutch

56P9624 Link - Link, frame

56P9668 Lock - Handle assembly, lock

56P9534 Magnet - Magnet, right side latch

56P9543 Magnet - Magnet, front cover latch

56P9900 Maintenance Kit - C910, C912 Fuser Maintenance Kit 110-120V

56P9901 Maintenance Kit - C910, C912 Fuser Maintenance Kit 220-240V

56P9903 Maintenance Kit - C910, C912 Transfer Belt Maintenance Kit

12G6509 Memory - 64MB SDRAM DIMM, 8MX64

56P9910 Memory - 128MB SDRAM DIMM

56P9911 Memory - 256MB SDRAM DIMM

56P9935 Memory - Traditional Chinese Font DIMM

56P9936 Memory - Simplified Chinese Font DIMM

56P9975 Memory - Japanese Font DIMM

56P9698 Motor - Motor assembly, 120 V

56P9699 Motor - Motor assembly, 230 V

56P9774 Motor - Motor, feeder drive

56P9803 Motor - Motor, duplex stepping

56P9828 Motor - Motor assembly, paper guide

12G1695 Network - MarkNet N2001e Ethernet 10/100BaseTX internal print server

12G7360 Panel - Operator Panel Assembly

99A1501 Panel - Operator Panel Assembly

40X3482 PC Board - Card, size sense

56P0161 PC Board - RS-232-C Serial/Parallel 1284-C Interface Card

56P9440 PC Board - Bar Code Card (C912)

56P9442 PC Board - ImageQuick Card (C912)

56P9522 PC Board - Board, size sensor

56P9701 PC Board - Board, sensor

56P9709 PC Board - Board, 120 V motor driver

56P9710 PC Board - Board, 230 V motor driver

56P9714 PC Board - Board, high voltage power supply

56P9742 PC Board - Board, heater drive

56P9776 PC Board - Board, paper remaining sensor

56P9779 PC Board - Board, expansion feeder control

56P9804 PC Board - Board, duplex interface

56P9868 PC Board - Board, high-capacity feed

56P9916 PC Board - Card, riser

56P9422 Pin - Pin, N

56P9449 Pin - Pin

56P9452 Pin - Pin, O

56P9667 Pin - Pin, upper unit support

56P9628 Pivot - Pivot, color link

11G0399 Plate - Ground Plate

56P9390 Plate - Plate, cover

56P9393 Plate - Plate, guide holder

56P9824 Plate - Plate, paper carrying drawer

56P9825 Plate - Plate, paper re-feed drawer

56P9994 Plate - Plate, duplex guide

56P9988 Post - Post, mini-S/N XX-1XXXX

11A9095 Power Cord - Power cord 2.5 m 8 ft. Straight US Canada Latin America (LV)

56P9722 Power Supply - Power supply, 120 V (1)

56P9723 Power Supply - Power supply, 230 V (1)

56P9724 Power Supply - Power supply, 120 V (2)

56P9725 Power Supply - Power supply, 230 V (2)

56P9599 Printhead - Printhead, LED -S/NXX-0XXXX

56P9406 Pulley - Pulley, Z24/T42 gear

56P9411 Pulley - Pulley

56P9414 Pulley - Pulley

56P9415 Pulley - Pulley, gear Z36/T24

56P9423 Pulley - Pulley, Z19/Z20

56P9450 Pulley - Pulley, wire A

56P9463 Pulley - Pulley, wire B

56P9576 Pulley - Pulley, face down feed roller

56P9818 Pulley - Pulley, carrying roller timing

56P9819 Pulley - Pulley, feed roller

56P9820 Pulley - Pulley, re-feed roller

56P9504 Rail - Rail, side

56P9505 Rail - Rail, side

56P9592 Rail - Rail, left side

56P9610 Rail - Rail, right side

56P9741 Resistor - Resistor, conditioning (230 V only)

56P9613 Rod - Rod, interlocking

56P9686 Rod - Rod, lock

18A1561 Roller - Roller assembly, paper feed

56P9377 Roller - Roller, D

56P9453 Roller - Roller, C

56P9512 Roller - Roller assembly, paper carrying

56P9514 Roller - Roller, noise reduction

56P9790 Roller - Roller, paper carrying

56P9796 Roller - Roller assembly, carrying

56P9809 Roller - Roller, drive feed

56P9810 Roller - Roller, follow-up feed

56P9811 Roller - Roller, middle feed

56P9812 Roller - Roller, re-feed

56P9813 Roller - Roll, release

56P9524 Screw - Screw, slide rail

56P9800 Screw - Screw, duplex mounting

56P9945 Screw - Screws Parts Packet

56P9946 Screw - Screws, Springs, E-rings Parts packet

56P9947 Screw - Screws, E-Rings Parts Packet

56P9948 Screw - Screws, E-Rings, Spring Pins Parts Packet

56P9949 Screw - Screws, E-Rings, Spring Pins Parts Packet

56P9950 Screw - Screws, E-Rings, Spring Pins Parts Packet

56P9951 Screw - Screws, Springs, E-Rings Parts packet

56P9952 Screw - Screws Parts Packet

56P9953 Screw - Screws, E-rings, C-Rings Parts packet

56P9954 Screw - Screws, E-Rings Parts Packet

56P9955 Screw - Screws, E-Rings Parts Packet

56P9956 Screw - Screws, E-Rings, Spring Pins Parts Packet

56P9957 Screw - Screws, E-Rings Parts Packet

56P9958 Screw - Screws Parts Packet

56P9959 Screw - Screws, E-Rings Parts Packet

56P9960 Screw - Screws Parts Packet

56P9961 Screw - Screws, E-Rings Parts Packet

56P9962 Screw - Screws, Washers, E-Rings Parts Packet

56P9963 Screw - Screws, E-Rings Parts Packet

11G0219 Sensor - Photo Interrupter, Sensor

56P9382 Sensor - Sensor, photo

56P9388 Sensor - Sensor, 1 photo

56P9502 Sensor - Sensor, turn guide door

56P9541 Sensor - Sensor, resistor

56P9645 Sensor - Sensor, drive unit gear

56P9665 Sensor - Sensor, paper feed

56P9676 Sensor - Sensor, density

11G0243 Service Parts - Photo Interrupter

11G0563 Service Parts - Photo Interrupter

40X2776 Service Parts - Right stop

40X2778 Service Parts - Left stop

56P1435 Service Parts - External Serial Adapter

56P9408 Service Parts - Knob

56P9448 Service Parts - Washer

56P9476 Service Parts - Stop, caster

56P9478 Service Parts - Caster

56P9525 Service Parts - Photo interrupter

56P9557 Service Parts - Exit assembly, face up

56P9734 Service Parts - HCF/finisher D-sub assembly

56P9808 Service Parts - Photo interrupter

56P9926 Service Parts - Optra Forms Software

56P9934 Service Parts - MarkNet N2000t 4/16 Token Ring internal print server

56P9964 Service Parts - Transformer, power (Japan only)

99A0424 Service Parts - Infrared Adapter

99A0560 Service Parts - Tri-Port Adapter (Serial, LocalTalk and Infrared)

56P9482 Shaft - Shaft, A

56P9510 Shaft - Shaft, paper feed

56P9662 Shaft - Shaft, changing

56P9993 Shield - Shield, light-used on P/N 56P9594

56P9632 Shroud - Shroud, cable

56P9670 Shroud - Shroud, cable

56P9535 Solenoid - Cover, solenoid

56P9700 Solenoid - Solenoid assembly, paper feed

56P9782 Solenoid - Spring, solenoid

56P9783 Solenoid - Solenoid, feeder

56P9829 Solenoid - Solenoid assembly, feed roller

56P9830 Solenoid - Solenoid assembly, paper re-feed

56P9412 Spacer - Spacer

56P9369 Spring - Assembly, spring plate C

56P9371 Spring - Spring

56P9378 Spring - Plate, E spring

56P9384 Spring - Plate, B spring

56P9403 Spring - Spring, A

56P9404 Spring - Spring, F

56P9468 Spring - Spring

56P9516 Spring - Spring, left cassette guide

56P9517 Spring - Spring, right cassette guide

56P9526 Spring - Spring, feed roller

56P9609 Spring - Spring, printhead

56P9614 Spring - Spring, return

56P9786 Spring - Spring, paper detection sensor

56P9791 Spring - Spring, paper carrying

56P9793 Spring - Spring, left turn guide

56P9794 Spring - Spring, right turn guide

56P9815 Spring - Spring, reed roller

56P9816 Spring - Spring, re-feed roller

56P9693 Stopper - Stopper, clutch

56P9666 Support - Support assembly, upper unit

56P9470 Switch - Switch, set

56P9707 Switch - Switch, power

56P9990 Tape - Tape, Core-S/N XX-1XXXX

56P9531 Tray - Tray assembly, exit

7370569 Tray - Relocation packaging kit, 500-Sheet Tray

56P9642 Unit - Unit, drive

Lexmark Laser C912 (5055-200)

Lexmark parts list for 5055-200 Lexmark Laser C912 Printer
