C7167V-AC_AdapterAC Adapter - Power supply module or adapter - one end for connecting to the printer and other end to the power cord, or your ac adapter may have the pwr cord attached.
C7167V-ADF_ArmADF Arm - Senses paper in the ADF area tray / feeder tray. this is a front flapper arm - part of the paper separation mechanism for the paper pickup assembly - mounts just in front of the front separation belts in the ADF assembly.
C7167V-ADF_Feed_AssyADF Feed Assembly - ADF assembly - does not include ADF input tray. ADF assembly includes the complete ADF assembly (motor, gears, rollers, sensor, does not include the ADF pad or plastic flatbed cover. (for entire unit please see ADF unit assembly).
C7167V-ADF_Input_TrayAdf Input Tray - ADF tray ( for automatic document feeder) this is where papers are placed for feeding into unit.
C7167V-ADF_MotorADF Motor - ADF motor - the scanner ADF motor is located on left rear corner of ADF drive, location varies from each unit. however, this is the main motor on the ADF unit.
C7167V-ADF_Output_TrayADF Out Put Tray - ADF out put tray is where paper come out of ADF (automatic document feeder). For this unit we will ship the entire ADF Assembly.
C7167V-ADF_PadADF Pad - ADF paper seperation pad assembly - mounts in the center of the ADF separation pad frame assembly. this pad prevents from multiple feeding or preventing paper jams while faxing scanning or copying.
C7167V-ADF_Roller_KitADF Roller Kit - ADF upper pick roller replacement kit. these are the rollers that feed paper into the feeder to be scan copy or faxed.
C7167V-ADF_ScannerADF Scanner - ADF scanner (optical) assembly - includes the chassis assembly scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - this is the lower assembly that scans copies documents.
C7167V-ADF_Sensor_BRDADF Sensor Board - ADF sensor pc board assembly - narrow strip pc board with the two document skew sensors, registration sensor, and timing sensor - mounts on top of the registration guide assembly in the ADF main assembly
C7167V-ADF_Unit_AssyADF Unit Assembly - Complete replacement assembly unit for Officejet Copier top assembly only. This includes the ADF (automatic document feeder) for this unit.
C7167V-Arm_DeliveryArm Delivery - Paper sensing arm - for 'paper out' or delivering paper sensing arm
C7167V-Arm_PickupArm Pick Up - Paper detection arm - for registration plate on picking up paper
C7167V-Belt_ADFBelt ADF - Transport belt motor - provides the drive to transport paper through the ADF unit. this belt goes in the ADF assembly drive unit
C7167V-Belt_DuplexBelt Duplex - Duplex timing belt - small belt that goes on the duplexer unit
C7167V-Belt_PaperBelt Paper - Paper drive belt (usually a small belt) - this belt attaches to a gear which is driven by the paper drive motor assembly.
C7167V-Belt_ScannerBelt Scanner - Scanner assembly belt. belt moves the scanner while copying or scanning documents.
C7167V-BezelBezel - Front panel overlay (bezel) - (english) control panel bezel - frame around display and control panel
C7160-16600Cable - Parallel extension cable with ferrite - DB-25 (M) connector to DB-25 (F) connector - 1.1m (3.6ft) long
C7167V-Cable_MchnsmCable Mechanism - Cable assembly which connects the main logic board to the print mechanism
C7167V-Cable_PanelCable Panel - Cable Panel assembly - includes ribbon cable this is the cable that connects to the control panel or display.
C7167V-Cable_USBCable USB - This interface cable is the standard 2.0 usb cable that connects to your printer and computer for printing.
C7167V-Carriage_CableCarriage Cable - Flex circuit cable which connects the head driver board to the carriage assembly. in some units it is also known as the trailing cable, this cable moves along with the carriage unit (side to side).
C7167V-Carriage_LatchCarriage Latch - A-arm latch - retains latch over the printheads on the carriage
C7167V-Carriage_Latch_CVRCarriage Latch Cover - The carriage latch is used to keep the cartridge(s) in place. this latch(s) hold the cartridge(s) in place while carriage is printing or idle.
C7167V-Carriage_MotorCarriage Motor - Carriage motor moves the carriage unit side to side. the carriage belt goes arround this motor, which controls carriage movement.
C7167V-Carriage_PC_BRDCarriage PC Board - This pc board attaches on the carriage, it is usually a small pc board that has carrage cable attached to it.
C7167V-ChassisChassis - Chassis assembly - the large plastic item that forms the base of the print mechanism
C7167V-Clutch_ADFClutch ADF - ADF paper clutch unit. clutch that controls movement on the ADF feeder
C7167V-Clutch_FeedClutch Feed - Clutch unit resposible for unit picking up paper from the pick up unit.
C7167V-Control_PanelControl Panel - Control panel assembly - control buttons and display on top front of the unit.
C7167V-Cover_BackCover Back - Back cover of printer, it is usually removed to clear paper jams.
C7167V-Cover_CartridgeCover Cartridge - This is the cover/ door that is opened to remove the cartridge(s) - usually, when this door opens the carriage moves.
C7167V-Cover_MainCover Main - This is the main cover of the printer. it is the biggest piece of plastic the printer is made off.
C7167V-Extender_ADFExtender ADF - Paper extension for the automatic document feeder (ADF) input tray
C7167V-Extender_InputExtender Input - Tray extension assembly (stopper) - tray with a paper stop on the input tray - extends to accomodate different media lenths
C7167V-Feed_RollersFeed Rollers - Feed roller assembly - includes frame asembly, shaft with rollers, and encoder disk
C7167V-Feed_Rollers_ADFFeed Rollers ADF - ADF feed roller kit - includes all rollers that feed paper through the feeder.
C7167V-Flag_ADFFlag ADF - Photo-sensor assembly - includes the sensor and mounting bracket - paper pickup roller home position sensor - activated by the sensor flag on the pickup roller assembly - mounths on the front frame of the ADF paper pickup assembly
C7167V-FormatterFormatter - Formatter board assembly, this board communicates with your computer device and has MAC port connector.
C7167V-Front_PanelFront Panel - Front panel assembly - includes lcd and actuator buttons
C7167V-Gear_MainGear Main - Paper pickup drive assembly - gear assembly located on right side of paper pickup assembly. gear moves the main paper pick up roller.
C7167V-Glass_ADF_WindowGlass ADF Window - Small glass piece used when scanning - copying - faxing with ADF feeder for this unit will ship Q5888-00002.
C7167V-Guide_PaperGuide Paper - Upper paper guide - spring loaded flat plate that presses the media against the top of the feed roller assembly - caution: this part can easily be broken
C7167V-Hinge_CvrHinge - Single cover end M-Hinge Hinge is for top cover supporting opening and closing of the cover. Most covers use 2 hinges this price includes 1pc Hinge.
C7167V-HolderHolder - Ink cartridge holder - located on carriage unit, holder secures ink cartridge in place.
C7167V-IdlerIdler - Scanner belt idler assembly - maintains scannter belt tension.
C7167V-Lid_Cover_AssyLid Cover Assy - Top glass copier cover. Lid that pressed document onto the glass for copying or scanning document.
C7167V-Motor_ADFMotor ADF - ADF motor unit - drives ADF rollers on the feeder assembly
C7167V-Motor_ScannerMotor Scanner - Scanner unit motor - drives the scanner unit to scan documents to be copied, fax, or scanned.
C7167V-OverlayOverlay - Overlay unit which covers the control button or display (english overlay only), control panel or display sold seperately.
C7167V-Pad_ADFPad ADF - Pad separator - (located on ADF unit) assembled from plastic and rubber components; to help in separating sheet of media during faxing, scanning, or copying.
C7167V-Pad_TrayPad Tray - Pad separator - (located on tray) assembled from plastic and rubber components; to help in separating sheet of media during printing
C7167V-PC_BRD_InterfacePC Board Interface - Internal print server lan interface board - plugs into peripheral eio. usefull for networking and multiple users.
8120-6326Power Cord - Power cord (Dove Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (for 240V in Australia, New Zealand, and China)
8120-6328Power Cord - Power cord (Dove Gray) - 18 AWG, 2.3m (7.5ft) long - Has straight (F) C13 receptacle (for 120V in the United States, Canada, Mexico, Taiwan, Latin America, and the Philippines)
8120-6329Power Cord - Power cord (Dove Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) C13 receptacle (for 240V in South Africa and India)
8120-6811Power Cord - Power cord (Flint Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) C13 receptacle (for 220V in Europe, Saudi Arabia, South Africa, India, and Korea)
8120-6813Power Cord - Power cord (Dove Gray) - Three Conductor, 2.3M (7.5ft) long - Has straight (F) C13 receptacle (For 240VAC in the United Kingdom, Hong Kong, Singapore, Malaysia)
8120-6869Power Cord - Power cord (Flint Gray) - 3-wire, 2.3m (7.5ft) long - Has straight (F) receptacle (for 220V in Argentina)
8120-6980Power Cord - Power cord (Flint Gray) - 18 AWG, 4.5m (14.8ft) long - Has straight (F) receptacle (for 220V in South America)
8120-8376Power Cord - Power cord (Flint Gray) - 17 AWG, 2.2m (7.3ft) long - Has straight (F) receptacle (for 220V in China)
8120-8706Power Cord - Power cord (Flint Gray) - 2.3m (7.5ft) long - Has EPSR symbol molded into the plug and straight (F) receptacle (for 220V in Hong Kong)
C7167V-Power_CordPower Cord - Power module power cord- wall outlet cable to power module only. does not include power module.
C7160-16500Power Module - Wall-mount power supply module (HiTRON HER-48-12010) - 120VAC input, 60Hz, 0.25A - 12VDC output, 1.0A, max 12 watts - Flat blade, non-polarized, ungrounded - Does not require separate AC power cord - For the USA
C7160-16501Power Module - Power supply module - Does not require separate AC power cord - Europe, Italy, Germany, Netherlands, France, Spain, Portugal
C7160-16502Power Module - Wall-mount power supply module (HiTRON HES10-12010-0-5) - 100-240VAC input, 50-60Hz, 0.33-0.19A - 12VDC output, 1.0A, max 12 watts - Does not require separate AC power cord - U.K.
C7160-16503Power Module - Power supply module (HiTRON HES10-12010-0-7) - 100-240VAC input, 50-60Hz, 0.33-0.19A, requires separate AC power cord - 12VDC output, 1.0A, max 12 watts - For worldwide use
C7167V-Power_MDLEPower Module - World wide power module - includes power module and power module to printer cord - does not include outlet to power module cord
C7167V-Repair_InkJetRepair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available.
C7167V-GuideService Guide - Printer Reference Guide (not a service manual) - Contains information such as product information, operation overview, paper behavior, maintenance, ink safety, and removal / replacement of parts. This is not a service manual for technical repair.
