C7296A-AbsorberAbsorber - Ink service station (ISS) bottom absorber foam - absorbs ink during the cleaning process. Service station absorber (sponge) - soaks up used ink during cartridge cleaning. Works as sled filters.
C7296A-AC_AdapterAC Adapter - Power supply module or adapter - one end for connecting to the printer and other end to the power cord, or your ac adapter may have the pwr cord attached.
C7296A-ActuatorActuator - Actuating unit. this part usually causes the carriage assembly to stalls on the left side of the printer, verify that the clutch actuator arm (slider arm).
C7296A-ADF_ArmADF Arm - Senses paper in the ADF area tray / feeder tray. this is a front flapper arm - part of the paper separation mechanism for the paper pickup assembly - mounts just in front of the front separation belts in the ADF assembly.
C7296A-ADF_Feed_AssyADF Feed Assembly - ADF assembly - does not include ADF input tray. ADF assembly includes the complete ADF assembly (motor, gears, rollers, sensor, does not include the ADF pad or plastic flatbed cover. (for entire unit please see ADF unit assembly).
C7296A-ADF_Input_TrayAdf Input Tray - ADF tray ( for automatic document feeder) this is where papers are placed for feeding into unit.
C7296A-ADF_MotorADF Motor - ADF motor - the scanner ADF motor is located on left rear corner of ADF drive, location varies from each unit. however, this is the main motor on the ADF unit.
C7296A-ADF_Output_TrayADF Out Put Tray - ADF out put tray is where paper come out of ADF (automatic document feeder). For this unit we will ship the entire ADF Assembly.
C7296A-ADF_PadADF Pad - ADF paper seperation pad assembly - mounts in the center of the ADF separation pad frame assembly. this pad prevents from multiple feeding or preventing paper jams while faxing scanning or copying.
C7296A-ADF_Roller_KitADF Roller Kit - ADF upper pick roller replacement kit. these are the rollers that feed paper into the feeder to be scan copy or faxed.
C7296A-ADF_ScannerADF Scanner - ADF scanner (optical) assembly - includes the chassis assembly scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - this is the lower assembly that scans copies documents.
C7296A-ADF_Sensor_BRDADF Sensor Board - ADF sensor pc board assembly - narrow strip pc board with the two document skew sensors, registration sensor, and timing sensor - mounts on top of the registration guide assembly in the ADF main assembly
C7296A-ADF_Unit_AssyADF Unit Assembly - Complete replacement assembly unit for Officejet Copier top assembly only. This includes the ADF (automatic document feeder) for this unit.
C7296A-Arm_DeliveryArm Delivery - Paper sensing arm - for 'paper out' or delivering paper sensing arm
C7296A-Belt_CarriageBelt Carriage - Carriage belt - moves the carriage assembly across the carriage rod
C7296A-Belt_DuplexBelt Duplex - Duplex timing belt - small belt that goes on the duplexer unit
C7296A-Belt_PaperBelt Paper - Paper drive belt (usually a small belt) - this belt attaches to a gear which is driven by the paper drive motor assembly.
C7296A-Belt_ScannerBelt Scanner - Scanner assembly belt. belt moves the scanner while copying or scanning documents.
C7296-40032Bezel - Bezel, scanner for HP DeskJet 6620 Series
C7296-40058Bezel - Bezel, fax pca for HP DeskJet 6620 Series
C7296A-BezelBezel - Front panel overlay (bezel) - (english) control panel bezel - frame around display and control panel
C8373-60001Bezel - OfficeJet D125xi Front Panel Bezel (English)
C8373-60002Bezel - OfficeJet D125xi Front Panel Bezel (French)
C7296A-Bracket_LeftBracket Left - Left bracket - carriage rod adjustment bracket (left)
C7296A-Bracket_RightBracket Right - Right bracket - carriage rod adjustment bracket (right)
C7296A-Bracket_TensionBracket Tension - Belt tension bracket - holds the carriage belt idler pulley
C7296A-Carriage_AssyCarriage Assembly - Ink cartridge carriage assembly - includes carriage, felt, felt retainers, ink cartridge latches, trailing cable, pc board, belt attachment hardware, and slider.
C7296A-Carriage_BaseCarriage Base - Carriage base or pre-loader assembly - mounted to bottom of carriage base
C7296A-Carriage_BeltCarriage Belt - Carriage drive belt, this belt is attached to the carriage and carriage motor, it moves the carriage side to side while priting.
C7296A-Carriage_CableCarriage Cable - Flex circuit cable which connects the head driver board to the carriage assembly. in some units it is also known as the trailing cable, this cable moves along with the carriage unit (side to side).
C7296A-Carriage_LatchCarriage Latch - A-arm latch - retains latch over the printheads on the carriage
C7296A-Carriage_Latch_CVRCarriage Latch Cover - The carriage latch is used to keep the cartridge(s) in place. this latch(s) hold the cartridge(s) in place while carriage is printing or idle.
C7296A-Carriage_MotorCarriage Motor - Carriage motor moves the carriage unit side to side. the carriage belt goes arround this motor, which controls carriage movement.
C7296A-Carriage_OnlyCarriage Only - Carriage only - includes carriage, felt, felt retainers, ink cartridge latches - does not include trailing cable, pc board, belt attachment hardware, or slider (for complete carriage unit, please see carriage assembly).
C7296A-Carriage_PC_BRDCarriage PC Board - This pc board attaches on the carriage, it is usually a small pc board that has carrage cable attached to it.
C7309-40128Cover - ADF cleanout assembly - Used to clear paper jams
C7309-40153Cover - Cleanout assembly strip - Green plastic bar with two grab tabs - Can be removed to help clear paper jams in the automatic document feeder assembly
C7296A-Cover_BackCover Back - Back cover of printer, it is usually removed to clear paper jams.
C7296A-Cover_CartridgeCover Cartridge - This is the cover/ door that is opened to remove the cartridge(s) - usually, when this door opens the carriage moves.
C7296A-Cover_MainCover Main - This is the main cover of the printer. it is the biggest piece of plastic the printer is made off.
C7296A-DeflectorDeflector - Paper deflector - guides paper out of dispose assembly - through the internal paper path cover. paper deflector - directs paper from the media chassis to the print section of the printer chassis assembly
C7296A-DisplayDisplay - Status led display (LCD display assembly).
C6436-60044Door - Rear door assembly - Removed when duplexer is present, this door allows for access and removal of paper jams
C7296A-Door_CarriageDoor Carriage - Main front access door - covers the top of the printer and provide access to the carriage when open.
C7296A-Door_CartridgeDoor Cartridge - Small front access door (drop down door) - for accessing print cartridge window - for print cartridge access door.
C7296A-Door_RearDoor Rear - Rear cleanout door assembly - rear paper jam clean out door assembly.
C7296A-Drive_AssyDrive Assembly - Paper drive roller kit - includes roller assembly, bushings, gear on roller, transmission gear kit, encoder disc, end thrust (axial) spring.
C7296A-Drive_Assy_ADFDrive Assy ADF - Media chassis assembly (paper drive) - moves paper from ADF assembly to scanner assembly - includes media chassis, rollers, gears, flag, sensor, deflector, cable, springs
C6437ADuplexer - Duplexer Assembly - Automatic two sided printing accessory
C6436-80010Encoder - Encoder strip (Clear strip with position marks) - Used by the sensor in the carriage assembly to determine position C8154 80028.
C7296A-EncoderEncoder - Encoder spring - provides tension for encoder strip
C7296A-Encoder_DiskEncoder Disk - Disk encoder - helps to provide position information of the paper
C7296A-Encoder_StripEncoder Strip - Encoder strip - carriage position sensor reference
C7296A-Extender_ADFExtender ADF - Paper extension for the automatic document feeder (ADF) input tray
C7296A-Extender_InputExtender Input - Tray extension assembly (stopper) - tray with a paper stop on the input tray - extends to accomodate different media lenths
C7296A-Flag_ADFFlag ADF - Photo-sensor assembly - includes the sensor and mounting bracket - paper pickup roller home position sensor - activated by the sensor flag on the pickup roller assembly - mounths on the front frame of the ADF paper pickup assembly
C7296A-Front_PanelFront Panel - Front panel assembly - includes lcd and actuator buttons
C7296A-Gear_AssyGear Assembly - ADF gear assembly driven by ADF main motor
C7296A-Gear_ClusterGear Cluster - Cluster gear, large gear on service station
C7296A-Gear_DoubleGear Double - Transfer gear - has double gear attached on service station
C7296A-Gear_MainGear Main - Paper pickup drive assembly - gear assembly located on right side of paper pickup assembly. gear moves the main paper pick up roller.
C7296A-Guide_PaperGuide Paper - Upper paper guide - spring loaded flat plate that presses the media against the top of the feed roller assembly - caution: this part can easily be broken
C7296A-HolderHolder - Ink cartridge holder - located on carriage unit, holder secures ink cartridge in place.
C7296A-IdlerIdler - Scanner belt idler assembly - maintains scannter belt tension.
C7296A-Motor_ADFMotor ADF - ADF motor unit - drives ADF rollers on the feeder assembly
C7296A-Motor_CarriageMotor Carriage - Carriage motor - motor that drives the carriage assembly
C7296A-Motor_ScannerMotor Scanner - Scanner unit motor - drives the scanner unit to scan documents to be copied, fax, or scanned.
C7296A-MTR_Srvce_StationMotor Service Station - Service station stepper motor (does not include cable) - moves the rack vertically in the service station assembly
C7296A-OverlayOverlay - Overlay unit which covers the control button or display (english overlay only), control panel or display sold seperately.
C7309-60009Pad - ADF paper separation pad assembly - Mounts in the center of the ADF separation pad frame assembly at the rear of the paper input tray
C7296A-Pad_ADFPad ADF - Pad separator - (located on ADF unit) assembled from plastic and rubber components; to help in separating sheet of media during faxing, scanning, or copying.
C7296A-Pad_TrayPad Tray - Pad separator - (located on tray) assembled from plastic and rubber components; to help in separating sheet of media during printing
C7296A-PC_BRDPC Board - Ink cartridge carriage assembly pc board - includes carriage pc board only
C7296A-PC_BRD_DCPC Board DC - Internal power supply board - power cable plugs on this assembly, remove covers to install pc board.
C7296A-PC_BRD_InterfacePC Board Interface - Internal print server lan interface board - plugs into peripheral eio. usefull for networking and multiple users.
C6436-67029Pickup Assembly - Pickup Roller Assembly - Shaft with large rollers and one gear
C7296A-PinchwheelPinchwheel - Pinch assembly kit - includes all required pinch wheels, pinchwheel mounts and springs
8120-6260Power Cord - Power cord (Black) - 18 AWG, 3-wire, 1.0m (3.3ft) long - Has straight (F) C13 receptacle (for USA, Canada, Taiwan, Latin America, and Saudi Arabia)
C7296A-Power_CordPower Cord - Power module power cord- wall outlet cable to power module only. does not include power module.
C7296A-Power_MDLEPower Module - World wide power module - includes power module and power module to printer cord - does not include outlet to power module cord
C7296A-Power_MDLE_AssyPower Module Assy - World wide power module - includes power module and power module to printer cord - also, include outlet to power module cord
C7296A-Power_SupplyPower Supply - Power supply board (internal pwr supply unit in the office machine).
C7296A-Print_MchnsmPrint Mechanism - Print mechanism assembly - complete mechanism with carriage movement, paper picking and service station - does not include covers, printer base, print heads, ink cartridges, or any consumables.
C7296-69001Printer - OfficeJet D135xi - Does not include ink cartridges, printheads, power module, or power cord
C7296A-PulleyPulley - Paper pick up tray motor pulley.
C8124-67020Rail - Paper pusher rail - Holds the paper pusher
C7296A-Repair_InkJetRepair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available.
C7296A-ScannerScanner - Copier scanner (optical) assembly - includes scanner assembly only scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly.
C7296A-Scanner_AssyScanner Assembly - Copier scanner & glass assembly - includes the chassis assembly scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly.
C7296A-Scanner_BeltScanner Belt - Scanner belt attaches from the scanner to the scanner motor.
C7296A-Scanner_CableScanner Cable - Flex circuit cable which connects to the scanner assembly. also known as flat cable, this cable moves along with the scanner unit (side to side) as it scans documents.
C7296A-Sensor_ADFSensor ADF - Photo-sensor assembly - includes the sensor and mounting bracket - paper pickup roller home position sensor - activated by the sensor flag on the pickup roller assembly - mounts on the front frame of the ADF paper pickup assembly
C7296A-Sensor_OutSensor Out - OOPS sensor - out of paper sensor - detects the presence of the paper in the printer tray
C7296A-Sensor_SpotSensor Spot - Spot sensor assembly is attached to the carriage assembly.
C7296A-SeparatorSeparator - Pad separator - assembled from plastic and rubber components; to help in separating sheet of media during printing from bottom trays.
C7296A-GuideService Guide - Printer Reference Guide (not a service manual) - Contains information such as product information, operation overview, paper behavior, maintenance, ink safety, and removal / replacement of parts. This is not a service manual for technical repair.
C7296A-SLED_AssySLED Assembly - Sled assembly - white plastic piece with spring, wipers and boot (assembly that the ink cartridge parks on) - mounts on top of the service station assembly
C7296A-SpeakerSpeaker - Speaker assembly - includes speaker cable.
C7296A-SpittonSpitton - Spittoon base - the bottom and main housing of the service station assembly - holds any residual ink from the print cartridge cleaning process
C6426-20008Spring - Envelope spring assembly - Aligns envelopes when inserted into the envelope feed slot
C8424-80005Spring - Idler spring for HP Digital Copier 310
C7296A-Spring_CmprsnSpring Compression - Compression spring - on pulley wedge for carriage belt tension
