CB770B-AbsorberAbsorber - Ink service station (ISS) bottom absorber foam - absorbs ink during the cleaning process. Service station absorber (sponge) - soaks up used ink during cartridge cleaning. Works as sled filters.
CB770B-AC_AdapterAC Adapter - Power supply module or adapter - one end for connecting to the printer and other end to the power cord, or your ac adapter may have the pwr cord attached.
CB770B-ActuatorActuator - Actuating unit. this part usually causes the carriage assembly to stalls on the left side of the printer, verify that the clutch actuator arm (slider arm).
CB770B-Arm_DeliveryArm Delivery - Paper sensing arm - for 'paper out' or delivering paper sensing arm
CB770B-Belt_CarriageBelt Carriage - Carriage belt - moves the carriage assembly across the carriage rod
CB770B-Belt_PaperBelt Paper - Paper drive belt (usually a small belt) - this belt attaches to a gear which is driven by the paper drive motor assembly.
CB770B-BezelBezel - Front panel overlay (bezel) - (english) control panel bezel - frame around display and control panel
CB770B-Bracket_LeftBracket Left - Left bracket - carriage rod adjustment bracket (left)
CB770B-Bracket_RightBracket Right - Right bracket - carriage rod adjustment bracket (right)
CB770B-Bracket_TensionBracket Tension - Belt tension bracket - holds the carriage belt idler pulley
CB770B-Cable_CarriageCable Carriage - Cable assembly which connects the main logic board to the carriage motor
CB770B-Cable_InterfaceCable Interface - Parallel cable - connects from your printer to computer via your parallel port.
CB770B-Cable_MchnsmCable Mechanism - Cable assembly which connects the main logic board to the print mechanism
CB770B-Cable_PanelCable Panel - Cable Panel assembly - includes ribbon cable this is the cable that connects to the control panel or display.
CB770B-Cable_USBCable USB - This interface cable is the standard 2.0 usb cable that connects to your printer and computer for printing.
CB770B-CamCam - Drawer cam - short, spring loaded lever attached to the paper tray frame - used to draw input tray into position
CB770B-Cap_LifterCap Lifter - These lifter caps hold the pressure plate lifter and the kicker spring in place.
UG119ECare Pack - HP 1 year Care Pack w/Next Day Exchange for Single Function Printers
UG604ECare Pack - HP 2 year Care Pack w/Next Day Exchange for Printers
UG607ECare Pack - HP 3 year Care Pack w/Next Day Exchange for Printers
UH608ECare Pack - HP 4 year Care Pack w/Next Day Exchange for Printers
US284ECare Pack - HP Basic Installation Service for one consumer printer with wireless capability
US285ECare Pack - HP Premium Installation Service with wireless network setup for up to three PCs and/or printers
CB770B-Carriage_AssyCarriage Assembly - Ink cartridge carriage assembly - includes carriage, felt, felt retainers, ink cartridge latches, trailing cable, pc board, belt attachment hardware, and slider.
CB770B-Carriage_BaseCarriage Base - Carriage base or pre-loader assembly - mounted to bottom of carriage base
CB770B-Carriage_BeltCarriage Belt - Carriage drive belt, this belt is attached to the carriage and carriage motor, it moves the carriage side to side while priting.
CB770B-Carriage_CableCarriage Cable - Flex circuit cable which connects the head driver board to the carriage assembly. in some units it is also known as the trailing cable, this cable moves along with the carriage unit (side to side).
CB770B-Carriage_LatchCarriage Latch - A-arm latch - retains latch over the printheads on the carriage
CB770B-Carriage_Latch_CVRCarriage Latch Cover - The carriage latch is used to keep the cartridge(s) in place. this latch(s) hold the cartridge(s) in place while carriage is printing or idle.
CB770B-Carriage_MotorCarriage Motor - Carriage motor moves the carriage unit side to side. the carriage belt goes arround this motor, which controls carriage movement.
CB770B-Carriage_OnlyCarriage Only - Carriage only - includes carriage, felt, felt retainers, ink cartridge latches - does not include trailing cable, pc board, belt attachment hardware, or slider (for complete carriage unit, please see carriage assembly).
CB770B-Carriage_PC_BRDCarriage PC Board - This pc board attaches on the carriage, it is usually a small pc board that has carrage cable attached to it.
CB770B-ChassisChassis - Chassis assembly - the large plastic item that forms the base of the print mechanism
CB770B-Clutch_FeedClutch Feed - Clutch unit resposible for unit picking up paper from the pick up unit.
CB770B-Control_PanelControl Panel - Control panel assembly - control buttons and display on top front of the unit.
CB770B-Cover_BackCover Back - Back cover of printer, it is usually removed to clear paper jams.
CB770B-Cover_CartridgeCover Cartridge - This is the cover/ door that is opened to remove the cartridge(s) - usually, when this door opens the carriage moves.
CB770B-Cover_MainCover Main - This is the main cover of the printer. it is the biggest piece of plastic the printer is made off.
CB770B-DeflectorDeflector - Paper deflector - guides paper out of dispose assembly - through the internal paper path cover. paper deflector - directs paper from the media chassis to the print section of the printer chassis assembly
CB770B-DisplayDisplay - Status led display (LCD display assembly).
CB770B-Door_CarriageDoor Carriage - Main front access door - covers the top of the printer and provide access to the carriage when open.
CB770B-Door_CartridgeDoor Cartridge - Small front access door (drop down door) - for accessing print cartridge window - for print cartridge access door.
CB770B-Door_RearDoor Rear - Rear cleanout door assembly - rear paper jam clean out door assembly.
CB770B-Drive_AssyDrive Assembly - Paper drive roller kit - includes roller assembly, bushings, gear on roller, transmission gear kit, encoder disc, end thrust (axial) spring.
CB770B-EncoderEncoder - Encoder spring - provides tension for encoder strip
CB770B-Encoder_DiskEncoder Disk - Disk encoder - helps to provide position information of the paper
CB770B-Encoder_StripEncoder Strip - Encoder strip - carriage position sensor reference
CB770B-Extender_InputExtender Input - Tray extension assembly (stopper) - tray with a paper stop on the input tray - extends to accomodate different media lenths
CB770B-FormatterFormatter - Formatter board assembly, this board communicates with your computer device and has MAC port connector.
CB770B-Front_PanelFront Panel - Front panel assembly - includes lcd and actuator buttons
CB770B-Gear_AssyGear Assembly - ADF gear assembly driven by ADF main motor
CB770B-Gear_ClusterGear Cluster - Cluster gear, large gear on service station
CB770B-Gear_DoubleGear Double - Transfer gear - has double gear attached on service station
CB770B-Gear_MainGear Main - Paper pickup drive assembly - gear assembly located on right side of paper pickup assembly. gear moves the main paper pick up roller.
CB770B-Guide_PaperGuide Paper - Upper paper guide - spring loaded flat plate that presses the media against the top of the feed roller assembly - caution: this part can easily be broken
CB770B-HolderHolder - Ink cartridge holder - located on carriage unit, holder secures ink cartridge in place.
CB770B-IdlerIdler - Scanner belt idler assembly - maintains scannter belt tension.
CB770B-Ink_DLVRYInk Delivery System - RIDS assembly - replaceable ink delivery system - transports ink from ink supply station to carriage assembly
CB767-90003Manual - Setup guide - For the Deskjet D1600 printer series
CB767-90007Manual - Basics guide - For the Deskjet D1600 printer series (English and German)
CB767-90008Manual - Basics guide - For the Deskjet D1600 printer series (Hebrew and Russian)
CB767-90009Manual - Basics guide - For the Deskjet D1600 printer series (Englsih, Arabic, French, Portuguese)
CB770B-Motor_CarriageMotor Carriage - Carriage motor - motor that drives the carriage assembly
CB770B-MTR_Srvce_StationMotor Service Station - Service station stepper motor (does not include cable) - moves the rack vertically in the service station assembly
CB770B-OverlayOverlay - Overlay unit which covers the control button or display (english overlay only), control panel or display sold seperately.
C6832APaper - Paper (Glossy) for DeskJet F4180 Series, HP Deskjet F4100 All-in-One printer series, DeskJet F4140 Series, DeskJet F4135 All-In-One
Q2519APaper - Paper (Glossy) for DeskJet D13XX Series, DeskJet D1311 Series, DeskJet F4180 Series, HP Deskjet F4100 All-in-One printer series
Q5451APaper - Paper (Glossy) for Photosmart 7400 Series, Photosmart 7450, PhotoSmart 8250 Series, PhotoSmart 8230 Series
Q5456APaper - HP Advanced Gloss Photo Paper 25 Sht
CB605-60067Paper Path Module - Cleanout assembly - Mechanical part assembled from molded plastic and steel components - Enables straight paper path for printing of thick media and odd sized media - Enables easier paper jam clearance
CB770B-PC_BRDPC Board - Ink cartridge carriage assembly pc board - includes carriage pc board only
CB770B-PC_BRD_DCPC Board DC - Internal power supply board - power cable plugs on this assembly, remove covers to install pc board.
CB770B-PC_BRD_InterfacePC Board Interface - Internal print server lan interface board - plugs into peripheral eio. usefull for networking and multiple users.
CB770B-PinchwheelPinchwheel - Pinch assembly kit - includes all required pinch wheels, pinchwheel mounts and springs
8121-0893Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For 240V in UK, Singapore, Malaysia, and Hong Kong, Opt. 955)
8121-0895Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For use in Europe, Opt. 954)
CB770B-Power_CordPower Cord - Power module power cord- wall outlet cable to power module only. does not include power module.
0957-2269Power Module - Power module - Input voltage 100-240VAC 50/60Hz 625mA - Output voltage 32VDC 20 watts - Requires a separate 2-wire AC power cord
CB770B-Power_MDLEPower Module - World wide power module - includes power module and power module to printer cord - does not include outlet to power module cord
CB770B-Power_MDLE_AssyPower Module Assy - World wide power module - includes power module and power module to printer cord - also, include outlet to power module cord
CB770B-Power_SupplyPower Supply - Power supply board (internal pwr supply unit in the office machine).
CB770B-Print_MchnsmPrint Mechanism - Print mechanism assembly - complete mechanism with carriage movement, paper picking and service station - does not include covers, printer base, print heads, ink cartridges, or any consumables.
CB767-69011Printer - Deskjet D1600 exchange unit - Does not included ink cartridges, power cord, or power module (Europe, Middle East, and Africa)
CB770B-PulleyPulley - Paper pick up tray motor pulley.
CB770B-Repair_InkJetRepair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available.
CB770B-Rod_CarriageRod Carriage - Carriage rod - shaft that the carriage assembly rides on
CB770B-Rod_ScannerRod Scanner - Scanner rod - shaft that the scanner assembly rides on
CB770B-Sensor_OutSensor Out - OOPS sensor - out of paper sensor - detects the presence of the paper in the printer tray
CB770B-Sensor_SpotSensor Spot - Spot sensor assembly is attached to the carriage assembly.
CB770B-SeparatorSeparator - Pad separator - assembled from plastic and rubber components; to help in separating sheet of media during printing from bottom trays.
CB770B-GuideService Guide - Printer Reference Guide (not a service manual) - Contains information such as product information, operation overview, paper behavior, maintenance, ink safety, and removal / replacement of parts. This is not a service manual for technical repair.
CB770B-Service_StationService Station - Service station assembly - for conditioning the printheads when the carriage is in its home position
CB770B-SLED_AssySLED Assembly - Sled assembly - white plastic piece with spring, wipers and boot (assembly that the ink cartridge parks on) - mounts on top of the service station assembly
CB770B-SliderSlider - Carriage base slider - plastic piece on the front end of the carriage that allows the carriage to slide side to side.
CB770B-SpeakerSpeaker - Speaker assembly - includes speaker cable.
CB770B-SpittonSpitton - Spittoon base - the bottom and main housing of the service station assembly - holds any residual ink from the print cartridge cleaning process
CB770B-Spring_CmprsnSpring Compression - Compression spring - on pulley wedge for carriage belt tension
CB770B-Trailing_CblTrailing Cable - Trailing cable for scanner - cable connects from scanner to pc board.
CB770B-Tray_AssyTray Assembly - Paper input tray assembly for loading paper (bottom).
CB770B-Tray_Assy_CVRTray Assembly Cover - Tray cover - the top cover for the paper pick up tray unit.
CB770B-Tray_BaseTray Base - Tray base- bottom base of the paper input tray.
CB770B-WindowWindow - Top/front access door assembly - print cartridge access door window.
Repair It
Exchange It
View Supplies
Service Manual
