RC1-0003-000CNArm - Toner cartridge arm - Mechanical link between main drive assembly and toner cartridge release mechanism
RC1-0714-000CNArm - Front door stop arm - Thin plastic arm between the front door and the lower frame - Provides a positive stop when the front door is opened
5090-3379Cleaner - Toner cleaning cloth - Specially treated cloth for absorbing toner or Ink (1 per package) - Ideal for cleaning up toner spills and Ink for your plotter / copier / printer
RC1-0486-020CNCover - Upper front cover - Small piece of plastic on top front edge of 500 sheet feeder
RC1-0487-020CNCover - Left side cover for 500 sheet paper feeder assembly
RC1-0488-020CNCover - Right side cover for 500 sheet paper feeder assembly
RC1-0500-020CNCover - Cover plate - Plastic cover on right front corner of 500 sheet feeder tray - Covers removable tray number designator plate. Part approaching End of Life, please contact HP for availability
RC1-0661-000CNCover - Right side cover assembly - For the 1,500 sheet paper feeder assembly
RC1-0662-000CNCover - Left side cover assembly - For the 1,500 sheet paper feeder assembly
RC1-0663-000CNCover - Rear cover assembly - Box type cover for the rear of the 1,500 sheet paper feeder assembly
RM1-0027-020CNCover - Rear output tray assembly - Includes upper rear paper output tray and cover
RM1-0273-070CNCover - Front cover (or door) - Provides access to load paper in the 1,500 sheet paper feeder assembly
RC1-0200-020CNDrive Assembly - Lifter drive assembly support - Tray 2 paper pickup lifter drive support assembly
RM1-0001-040CNDrive Assembly - Main drive assembly - Main gear assembly on right side of printer
RM1-0056-070CNDrive Assembly - Paper pickup drive assembly - Gear assembly on right front side of 500 sheet paper feeder assembly
RM1-0283-080CNDrive Assembly - Paper pickup drive assembly - Includes the drive gears and solenoid mounted on a bracket assembly
RM1-0287-040CNDrive Assembly - Lifter driver assembly - Includes the three drive gears, swing arm, tension spring and door open sensor
Q2439-69002Duplexer - Automatic duplexer assembly - For LaserJet 4200/4250 and 4300/4350 series printers
Q2439-69003Duplexer - Automatic duplexer assembly - For LaserJet 4200/4250 and 4300/4350 series printers
Q2439BDuplexer - Automatic duplexer assembly - For LaserJet 4200/4250 and 4300/4350 series printers
RK2-0278-000CNFan - Cooling fan - Located on left side of printer (FN101)
RK2-0280-000CNFan - Cooling fan (FN105) - Located on right side of printer - Provides air to the print cartridge area
5851-4076Feeder - Paper feed assembly - Includes tray 1 paper feed sensor flag, torsion spring, and paper feed roller assembly
Q2438-67902Feeder - Envelope feeder assembly - Holds up to 75 envelopes - Mounts in the tray 1 slot on the front of the printer
Q2438BFeeder - Envelope feeder assembly - Holds up to 75 envelopes - Mounts in the tray 1 slot on the front of the printer - Includes the envelope tray and multi-lingual installation instructions
RC1-0060-050CNFeeder - Paper feed assembly - Includes tray 1 paper feed sensor flag, torsion spring, and paper feed roller assembly
RC1-0061-000CNFeeder - Paper feed assembly - Includes tray 1 paper feed sensor flag, torsion spring, and paper feed roller assembly
RM1-0012-000CNFeeder - Paper feed assembly - Includes torsion spring and paper feed roller assembly
92296TFilm - Film (Transparency) for LaserJet II, LaserJet III, LaserJet 4 Series, LaserJet 4L Series
92296UFilm - Film (Transparency) for LaserJet 33x0 MFP Seriess, LaserJet 4100 Series, LaserJet P2xxx Printer, Color LaserJet CM1015 MFP
RC1-0161-000CNFlag - Paper size sensing flag - White plastic arm used as mechanical link to tray size sensor PC Board - Three used per sensing assembly
RC1-0209-020CNFlag - Paper sensor flag for Tray 2 paper pickup assembly
RM1-0012-020CNFlag - Paper feed assembly - Includes torsion spring and paper feed roller assembly
Q2425-69017Fuser Assembly - Fuser assembly for LaserJet 4200 series - 110 volt Fuser assembly for LJ 4200 series - 110 volt Bonds toner to paper with heat - For 100 to 127VAC operation
Q2425-69018Fuser Assembly - Fuser assembly for LaserJet 4200 series - 220 volt
RC1-3324-000CNGear - Fuser gear unit 40t driven by swing plate assembly unit. Gear attaches to fuser unit and driven by swing plate.
RU5-0045-020CNGear - 18 tooth gear - Located on right side of printer in the Tray 2 paper pickup assembly
RU5-0050-000CNGear - 30 tooth gear - Black plastic gear that attaches to paper feed assembly clutch
RU5-0088-000CNGear - 18 tooth gear - Located on right side of printer in the 500 sheet tray paper pickup assembly
RM1-0002-030CNGear Assembly - Duplexing pendulum assembly - Gear assembly that transfers power from main motor to run duplexing capability
RM1-0286-020CNGear Assembly - Paper level sensor gear assembly
RC1-0153-030CNGuide - Right side Tray 2 paper cassette guide
RC1-0244-000CNGuide - Support guide - Supports right rear side of power supply board
RC1-0343-020CNHolder - Thermistor holder - Metal outside half of thermistor holder
Q2425-67901Label - LaserJet 4200 series name plate kit - Includes all model labels for LaserJet 4200 series and one HP jewel label used on drop down Tray 1
5851-2766Lever - Swing plate assembly kit - For Tray 2 paper lift assembly - Located between the main gear assembly and the fuser, just above the power supply - Contains swing plate assembly and new fuser pressure release gear
RF5-3898-000CNLever - Laser scanner shutter lever - (one pc) Four used on this printer. One for each scanner assembly.
RM1-0043-060CNLever - Swing plate assembly - Pressure Roller GearSwing plate assembly - For tray 2 paper lift assembly Located between the main gear assembly and the fuser, just above the power supply. swing plate assembly usually comes with black and white large gears.
RM1-0033-040CNLifter - Tray 2 lifter drive assembly - Provides lift support for paper tray
RM1-0208-000CNLifter - Tray lifter drive assembly - Lifts paper tray as paper is used in 500 sheet tray
Q2429-69001Maintenance Kit - LaserJet 4200 maintenance kit - For 120 VAC operation - Includes fusing assembly, separation roller, transfer roller, feed roller for tray 1, two feed rollers for the 500-sheet tray, one feed roller for 1500-sheet tray
Q2429-69004Maintenance Kit - LaserJet 4200 maintenance kit - For 120 VAC operation - Includes fusing assembly, separation roller, transfer roller, feed roller for tray 1, two feed rollers for the 500-sheet tray, one feed roller for 1500-sheet tray
Q2429-69005Maintenance Kit - LaserJet 4200 maintenance kit - For 120 VAC operation - Includes fusing assembly, separation roller, transfer roller, feed roller for tray 1, two feed rollers for the 500-sheet tray, one feed roller for 1500-sheet tray and installation instructions
Q2429AMaintenance Kit - LaserJet 4200 maintenance kit - (120V) - Includes fusing assembly, separation roller, transfer roller, feed roller for Tray 1, two feed rollers for 500 sheet tray, one feed roller for 1500 sheet tray and installation instructions
Q2430-69005Maintenance Kit - LaserJet 4200 maintenance kit - (220V) - Includes fusing assembly, separation roller, transfer roller, feed roller for Tray 1, two feed rollers for 500 sheet tray, one feed roller for 1500 sheet tray and installation instructions
Q2430AMaintenance Kit - LaserJet 4200 maintenance kit - (220V) - Includes fusing assembly, separation roller, transfer roller, feed roller for Tray 1, two feed rollers for 500 sheet tray, one feed roller for 1500 sheet tray and installation instructions
5851-1890Manual - LaserJet part list booklet - Covers LaserJet 1005, 1010, 1012, 1015, 1200, 2300, 3300mfp, 4100mfp, 5000, 5100, 8150 and 9000 series printers - Volume I - This is only listing of service parts for these printers
5851-1891Manual - LaserJet quick reference service guide (monochrome) - Volume IV
Q2431-90916Manual - LaserJet 4200/4300 combined product family service manual
C4286AMemory - 2MB flash DIMM memory - Font storage device
C4287AMemory - 4MB flash DIMM memory - Font storage device
C4292AMemory - 8MB Traditional Chinese MROM DIMM - For LaserJet printers
C4293AMemory - 8MB simplified Chinese MROM DIMM - For LaserJet printers
C4179BPaper - Soft gloss Color LaserJet paper - A4 size (21.0cm x 29.7cm) - 200 sheets per package
Q1298APaper - LaserJet Satin finish tough paper - A size (8.5 x 11-inches) - Will not tear and will withstand outdoor weather conditions - Can print on both sides
Q1298BPaper - LaserJet Satin finish tough paper - A4 size (21.0cm x 29.7cm) - Will not tear and will withstand outdoor weather conditions - Can print on both sides - 50 sheets per box
Q2415APaper - Soft gloss LaserJet paper - Soft gloss finish on both sides, 95 brightness - A size (8.5 x 11-inches) - 500 sheets per box
Q2417APaper - Soft gloss LaserJet paper - Soft gloss finish on both sides, 95 brightness - A4 size (21.0cm x 29.7cm) - 250 sheets per box
Q2419APaper - High gloss LaserJet paper - High gloss finish on both sides, 95 brightness - A size (8.5 x 11-inches) - 200 sheets per box
Q2421APaper - High gloss LaserJet paper - High gloss finish on both sides, 95 brightness - A4 size (21.0cm x 29.7cm) - 200 sheets per box
Q6541APaper - HP Color Laser Soft-gloss Presentation Paper - A size (8.5 x 11-inches) - 200 sheets
Q2443-67908Paper Stacker - 500-Sheet paper stacker/stapler assembly - Provides additional output capacity and can staple output copies for the LaserJet 4200 or 4300 printers - Mounts on top of the printer
RG1-4200-000CNPC Board - Paper feeder assembly PC Board - PC Board on right side of 500 sheet paper feeder assembly
RG1-4236-040CNPC Board - DC controller board - DC Controller for LaserJet 4200 series Part RG1-4236-030CN is no longer supplied. Please order the replacement, RG1-4236-040CN
J4135APC Board Interface - JetDirect connectivity card - Has one USB port, one serial (DB9) port, and one LocalTalk port - Plugs in one of the EIO slots on selected DesignJet and LaserJet printers
J4167APC Board Interface - JetDirect 610N token ring LAN interface board - DB-9 and RJ-45 connectors
J6057ARPC Board Interface - JetDirect 615N internal print server (10Base-T and 100Base-TX) LAN interface board - Plugs into peripheral EIO slot - Has a RJ-45 connector - Comes with software on CD-ROM and manual
J7934GPC Board Interface - HP JetDirect 620n internal print server - 10BaseT and 100BaseTX LAN interface board - Plugs into peripheral EIO slot - Has an RJ-45 connector - Comes with software on CD-ROM and manual on CD-ROM
J7960GPC Board Interface - HP Jetdirect 625n internal ethernet print server - Provides 10BaseT, 100BaseTX, or 1000BaseT interface for products with an EIO port
RM1-0034-070CNPickup Assembly - Paper pick-up assembly - Paper pickup drive assembly for tray 2 input tray - Does not include the 18-tooth gear - In order to install this part the 18-tooth gear must be removed and replaced
RM1-0043-010CNPlate - Swing plate assembly - Pressure Roller GearSwing plate assembly - For tray 2 paper lift assembly Located between the main gear assembly and the fuser, just above the power supply. swing plate assembly usually comes with black and white large gears.
RM1-0043-020CNPlate - Swing plate assembly - Pressure Roller GearSwing plate assembly - For tray 2 paper lift assembly Located between the main gear assembly and the fuser, just above the power supply. swing plate assembly usually comes with black and white large gears.
RM1-0043-050CNPlate - Swing plate assembly - Pressure Roller GearSwing plate assembly - For tray 2 paper lift assembly Located between the main gear assembly and the fuser, just above the power supply. swing plate assembly usually comes with black and white large gears.
8120-6805Power Cord - Power cord (Flint Gray) - 18 AWG, 2.3m (7.5ft) long - Has 90 degree receptacle (for 120V in the USA, Canada, Mexico, Philippines, and Taiwan)
Q2425-69015Power Supply - Power supply assembly - 110VAC
Q2425-69016Power Supply - Power supply assembly - 220V
RC1-0268-000CNRod - Metal rod between external power button and switch on power supply board
5851-3941Roller - Roller kit - Includes the paper pick-up roller and the paper feed/separation roller assembly
KIT42-69005Roller - Laser roller kit assembly includes: one - 1 Transfer Roller, 6 - feed Rollers, one - 1 pickup D-roller tray 1, one - 1 separation pad, and transfer roller tool. See replacement instructions on website, printer tech help.
Q7829-67925Roller - Feed roller high capacity input (HCI) - Transmit the paper from the cassette and feeds it to the device entrance (blue)
RC1-0070-000CNRoller - Pressure roller - Roller in fusing assembly that provides pressure for media against the fusing roller
RL1-0019-000CNRoller - Tray 1 pickup roller - D-shaped roller located under the envelope cover
RM1-0015-000CNRoller - Fusing roller assembly - 110 volt
RY7-5217-000CNRoller - Roller kit - Includes the paper pick-up roller and the paper feed/separation roller assembly
XA9-1316-000CNScrew - M4X10 Phillips screw with broad flat washer head - Sheet metal thread
XB4-7300-605CNScrew - Screw - 6 mm Phillips head screw with attached washer
RC1-0748-000CNSensor - Paper size sensor block - Spring loaded block which activates the paper size sensor fingers
RK2-0359-000CNSensor - Environment temperature detection thermistor - Detects ambient air temperature to determine length of time for fuser warm up.
RM1-0041-020CNSensor - Tray 2 paper size tray sensing assembly - White plastic tray size sensing fingers and microswitch assembly
RM1-0055-000CNSensor - Paper feed shaft assembly - Not available as an assembly - Order feed roller shaft, pickup arm holder, pickup arm, pickup arm compression spring and Tray 2 sensor
RM1-0285-000CNSensor - Paper sensor assembly - Includes the support tray with the paper stack surface and paper detection sensors, associated sensor flags, and cable assembly. Part approaching End of Life, please contact HP
RM1-0294-000CNSensor - Paper size sensor assembly - Includes the three size fingers, micro-switch assembly and housing assembly
WG8-5624-000CNSensor - Replacement for part WG8-5362-000CN ORDER WG8-5624-000CN PHOTO-INTERRUPTER TLP1241 Photo-sensor (TLP1241) - Sensor flag activated
C8530AService Parts - 8MB Flash DIMM\TO ORDER SEE DESCRIP
RC1-0210-020CNShaft - Feeder roller shaft - Axel for Tray 2 feed roller
RM1-0053-000CNShutter - Left side shutter assembly - Blocks light from scanner on left side
RM1-0054-000CNShutter - Right side shutter assembly - Blocks light from scanner on right side
RC1-0198-000CNSpring - Tension spring - Provides tension for lifter drive assembly
RC1-0213-000CNSpring - Compression spring - Provides pressure for paper pickup and feed rollers in Tray 2 pickup assembly
Q2445-67902Stand - Printer stand with storage cabinet
Q2445BStand - HP printer stand & cabinet (LJ4200/4300)
RC1-0344-020CNSupport - Fan cover - Metal support strap that main cooling fan fastens to - For fan FN101, main cooling fan on right left side of printer
RM1-0043-000CNSwing - Swing plate assembly - Pressure Roller GearSwing plate assembly - For tray 2 paper lift assembly Located between the main gear assembly and the fuser, just above the power supply. swing plate assembly usually comes with black and white large gears.
WC4-5139-000CNSwitch - Top cover interlock access switch
RC1-0335-000CNTorque Limiter - Torque limiter - Torque limiter for 500 sheet paper feeder pickup roller
RM1-0007-190CNTransfer Assembly - Paper transfer assembly
RM1-0005-020CNTray - Drop down Tray 1 - Includes adjustable paper width guide assembly
RM1-0028-060CNTray - Tray-500 Sheet - 500-sheet tray/cassette - This is only the tray, does not include feeder or frame that tray goes into.
RM1-1088-090CNTray - 500-sheet tray/cassette - This is only the tray, does not include feeder or frame that tray goes into.
Q2440-67903Tray Assembly - 500-sheet paper feeder and tray/cassette - This is the assembly frame and tray that the printer sits on top of
Q2440BTray Assembly - 500-sheet paper feeder and tray/cassette - This is the assembly frame and tray that the printer sits on top of
Q2444-67902Tray Assembly - 1500 sheet paper tray and feeder assembly for LaserJet 4200/4300 series printers
RM1-0004-110CNTray Assembly - Tray 1 paper input assembly unit for Hewlett Packard LaserJet printers.
